Поз.
Артикул
Описание
300
PROPELLER SHAFT FROM TRANSMISSION TO INTERMEDIATE BEARING 720 MM,4 277508-4 609737 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
300
PROPELLER SHAFT FROM TRANSMISSION TO INTERMEDIATE BEARING 846 MM,4 277507
315
DRIVE FLANGE
315
DRIVE FLANGE , Replaced By: A3524110011
318
UNIVERSAL JOINT CROSS WITH BUSHINGS, IF REQUIRED,ORDER LOCK RINGS ADDITIONALLY
321
GREASE NIPPLE
324
SNAP RING2.700 MM
324
SNAP RING2.650 MM
324
SNAP RING2.550 MM
324
SNAP RING2.600 MM
324
SNAP RING2.750 MM
324
SNAP RING2.500 MM
336
PROTECTIVE CAP , INTERMEDIATE BEARING, BALL BEARING IN RUBBER SEAT
336
PROTECTIVE CAP , INTERMEDIATE BEARING, BALL BEARING WITH LOCK
339
SCREW MOUNTING USED FOR FRAME CONNECTION PARTS
339
SCREW MOUNTING USED FOR FRAME CONNECTION PARTS
339
SCREW , Replaced By: A0079901001
342
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
345
NUT FROM PROPELLER SHAFT TO FRONT AXLE
400
INTERMEDIATE BEARING PROPELLER SHAFT, INTERMEDIATE BEARING, BALL BEARING IN RUBBER SEAT
400
INTERMEDIATE BEARING , Replaced By: A3814101222
400
INTERMEDIATE BEARING , Replaced By: A3855860041
400
INTERMEDIATE BEARING , INTERMEDIATE BEARING, BALL BEARING WITH LOCK, Replaced By: A3814101522, +002A3814130461, +004N000933010105
400
REPAIR KIT , Replaced By: A3814100222
400
REPAIR KIT , Replaced By: A3854100010
500
PROPELLER SHAFT ,4 277507 BEARING BUSHING O.D.,38 MM, Replaced By: A6744102102
500
PROPELLER SHAFT FROM INTERMEDIATE BEARING TO REAR AXLE 1319 MM,4 277508-4 609737 BEARING BUSHING O..D.,38 MM
500
PROPELLER SHAFT FROM TRANSFER CASE TO FRONT AXLE 1151 MM, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
515
DRIVE FLANGE
515
DRIVE FLANGE
515
DRIVE FLANGE , Replaced By: A3524110011
518
UNIVERSAL JOINT CROSS , Replaced By: A0004104031
518
UNIVERSAL JOINT CROSS WITH BUSHINGS
518
UNIVERSAL JOINT CROSS WITH BUSHINGS, IF REQUIRED,ORDER LOCK RINGS ADDITIONALLY
521
GREASE NIPPLE
524
LOCK AS REQUIRED 2.00 MM
524
LOCK AS REQUIRED 1.88 MM
524
SNAP RING2.700 MM
524
SNAP RING2.550 MM
524
SNAP RING2.650 MM
524
LOCK RING SHIFT LEVER BEARING
524
SNAP RING2.750 MM
524
SNAP RING2.600 MM
524
LOCK AS REQUIRED 1.75 MM
524
SNAP RING2.500 MM
525
BOOT
526
WIRE RING , WITH BOOT
528
CLAMP , WITH BOOT
539
SCREW MOUNTING USED FOR FRAME CONNECTION PARTS
539
SCREW MOUNTING USED FOR FRAME CONNECTION PARTS
539
SCREW , Replaced By: A0079901001
542
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
545
NUT FROM PROPELLER SHAFT TO FRONT AXLE
999
SEAL RING PROTECTIVE TUBE 74.5X22 MM
999
NEEDLE , Replaced By: A3189810287
999
EXPANSION PLUG
999
NEEDLE SET164 PIECES, BEARING BUSHING O..D.,38 MM
999
BEARING BUSHING
999
SEAL RING PROTECTIVE TUBE 77X14,5 MM
999
GREASE NIPPLE , Replaced By: N071412008102
999
GREASE NIPPLE
