Поз.
Артикул
Описание
10
FLOOR SHIFT , THEFT-RELEVANT PART
10
FLOOR SHIFT , F 06943420031031804 THEFT-RELEVANT PART UP TO IDENT F012131 ALL SWITCHES OF THE LOWER CONTROL PANEL TO BE ORDERED AS FOR VEHICLE EQUIPMENT
10
FLOOR SHIFT , F 04357920031031803 THEFT-RELEVANT PART
20
SELECTOR LEVER HANDLE , Replaced By: A2302676410
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE , F 07104820040730804 9E38 Y94QFT230A5070 BLACK
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE , F 07104820040730804 9E38 Y94QFT230A5070 BLACK
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE , 9B97 Y86QFT230A5008 BLACK
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER
20
SELECTOR LEVER HANDLE , F 07104820040730804 9E38 Y94QFT230A5070 BLACK
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE , F 07104820040730804 9E38 Y94QFT230A5070 BLACK
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE , 9E38 X00-809-X08-X25/X50-809-X08-X25QFT230A5015 BLACK
20
SELECTOR LEVER HANDLE , 9B97QFT230A5100 BLACK
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE , 9E38 X00-809-X08-X25/X50-809-X08-X25QFT230A5015 BLACK
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE , F 07104820040730804 9E38 Y94QFT230A5070 BLACK
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE , 9E38 X00-809-X08-X25/X50-809-X08-X25QFT230A5015 BLACK
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE , 9E38 X00-809-X08-X25/X50-809-X08-X25QFT230A5015 BLACK
20
SELECTOR LEVER
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE , F 10996620050623806 9E38 X00/X50QFT230A5060 BLACK
20
SELECTOR LEVER HANDLE , F 07104820040730804 9E38 Y94QFT230A5070 BLACK
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE , 9E38 X00-809-X08-X25/X50-809-X08-X25QFT230A5015 BLACK
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER
20
SELECTOR LEVER HANDLE , 9E38 X00-809-X08-X25/X50-809-X08-X25QFT230A5015 BLACK
20
SELECTOR LEVER HANDLE
20
SELECTOR LEVER HANDLE
30
SCREW-AND-WASHER ASSEMBLY BEARING BRACKET TO TUNNEL, A 04744920050930
30
SCREW
35
FUSE WIRE CABLE TO FLOOR SHIFT MECHANISM
40
CABLE PULL
40
CABLE PULL SHIFTING LOCK
50
COVER SLOTTED GATE, F 15700020081130809
50
COVER , F 04357920031031803 F 16012820090731800
50
COVER , F 04357920031031803
50
COVER SLOTTED GATE, F 06943420031031804 UP TO IDENT F012131 ALL SWITCHES OF THE LOWER CONTROL PANEL TO BE ORDERED AS FOR VEHICLE EQUIPMENT
50
COVER SLOTTED GATE, F 04357920031031803
50
COVER , F 16012820090731800
50
COVER SLOTTED GATE, F 15700020081130809
60
SNAP RING AT COVERING
70
SHIFTING ROD
80
ROD REAR
90
FUSE SHIFTING ROD TO GEAR SELECTOR LEVER, F 34175320090331 R 04430820080707
100
BUSHING
110
ROLL PIN3.5X18
110
ROLL PIN
120
SCREW , FROM MODEL YEAR'97
130
LOCKING PIN SHIFTING ROD
130
BOLT SHIFTING ROD M8X7, Replaced By: A2302670074
140
PIN LOCK SHIFTING ROD
145
FUSE SHIFTING ROD TO GEAR SELECTOR LEVER, F 34175320090331 R 04430820080707
900
PIN BUSHING HOUSING WARNING DEVICE
901
CONTACT BUSHINGR 27, 0.75 MM2
905
PLUG HOUSING. PIN BUSHING HOUSING SEAT ADJUSTMENT SWITCH, A 394035 X 004165, J 036478 EXCEPT CODE 808 ALSO INSTALLED IN VEHICLE FROM A 394036 / X 004166 WITH CODE 807
906
REP.SET CONTACT0.75 MM2 MQS, CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED. SEE WIS FOR REPAIR INSTRUCTIONS.SOLDER CONNECTOR SLEEVES:TOTAL WIRE CROSS-SECTION: A 001 546 99 41GREEN0.7 -2.4 MM2 A 002 546 00 41RED2.0 -4.0 MM2 A 002 546 01 41BLUE 3.5 -8.0 MM2 A 002 546 11 41YELLOW 7.5 - 12.0 MM2 BUTT JOINT: A 002 546 13 41 0.5 MM2 A 002 546 14 41 0.8 MM2 A 002 546 15 41 1.3 MM2 A 002 546 16 41 2.0 MM2
906
CONTACT BUSHINGR 27, 0.75 MM2
910
PLUG PROGRAM SELECTOR KEY 3-PIN MQS,S16/12
911
CONTACT BUSHINGR 27, 0.75 MM2
