Поз.
Артикул
Описание
5
FUEL TANK400 L.,4 399369
5
FUEL TANK , Replaced By: A3874700701
10
SENDER UNIT , Replaced By: A0085428117
10
SENDER UNIT , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 169122, Replaced By: A0115426517, +001A0005409917
15
SUPPORT FUEL TANK TO FRAME
20
SUPPORT FUEL TANK TO FRAME
25
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
25
SCREW BRACKET TO CAB CONSOLE,K 035197
30
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
35
NUT BRACKET TO SIDE MEMBER
35
NUT , Replaced By: N910113014001
40
WASHER TRAILER COUPLING TO REAR CROSS MEMBER
40
WASHER , Replaced By: A3379900440
45
SHIM CONSOLE TO SIDE MEMBER,4 939098
50
REINFORCEMENT AT CROSS MEMBER
55
SHIM CONSOLE TO SIDE MEMBER
65
SCREW SUPPORT TO CROSS MEMBER M 10X28
70
WASHER RADIATOR TO RUBBER MOUNTING
70
WASHER , Replaced By: N000125010532
75
NUT , Replaced By: N910113010000
75
NUT STRAP TO BRACKET
80
SCREW , Replaced By: N304017008021
80
SCREW PIPE CLAMP
85
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
85
NUT , Replaced By: N913004008001
90
SUPPORT CONSOLE TO SIDE MEMBER,4 8605904 972492
95
SHIM CONSOLE TO SIDE MEMBER,4 860590
100
REINFORCEMENT FUEL TANK CONSOLE
105
SCREW CONSOLE TO SIDE MEMBER
110
WASHER
115
NUT SUPPORT TO SIDE MEMBER
120
PAD FUEL TANK TO CONSOLE
120
PAD FUEL TANK TO CONSOLE, ORDER BY THE METER
125
PAD FUEL TANK TO SUPPORT 1060 MM
125
PAD FUEL TANK TO SUPPORT, ORDER BY THE METER
130
STRAP FUEL TANK TO SUPPORT
135
PIN STRAP TO SUPPORT
145
NUT STRAP TO SUPPORT
999
SENDER UNIT ,4 312465
999
WASHER BRACKET TO SIDE MEMBER,5 703114
999
STRAP ,4 6901025 149419, Replaced By: A6174700440, +001N000934012022
999
FUEL TANK , Replaced By: A3834701101, +001N007603014302, +001N007604014106
999
SUPPORT ,4 829902
999
CROSS MEMBER CONSOLE TO SIDE MEMBER,4 8605914 972491
999
SHIM ,4 8605914 972491
999
SUPPORT REAR
999
SUPPORT FRONT
999
SHIM ,4 8605914 972491
999
SHIM , Replaced By: A3854750184
999
STRAP ,5 149419, Replaced By: A6204700340, +001N000934012022
999
FUEL TANK , Replaced By: A3874701301
999
SHIM CONSOLE TO SIDE MEMBER
999
SHIM FUEL TANK
999
COTTER PINROCKINGER TYP 260 G140
999
SCREW , Replaced By: N308676012026
999
SCREW , Replaced By: N308676014020
999
SCREW BRACKET TO SIDE MEMBER
999
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
999
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
