Поз.
Артикул
Описание
4
FRONT SPRING 12-LEAF
8
SPRING LEAFTO 389 320 04 02,5 225134-5 232113 FOR USE WITH 12-LEAF FRONT SPRINGS
12
SPRING LEAFTO 389 320 00 04,5 225134-5 232113 FOR USE WITH 12-LEAF FRONT SPRINGS
16
SPRING LEAFTO 389 320 04 02,5 225134-5 232113 FOR USE WITH 12-LEAF FRONT SPRINGS
20
SPRING LEAFTO 389 320 04 02,5 225134-5 232113 FOR USE WITH 12-LEAF FRONT SPRINGS
20
SPRING LEAF , Replaced By: A3953210013
20
SPRING LEAF , Replaced By: A3463215613
24
SPRING LEAFTO 389 320 04 02,5 225134-5 232113 FOR USE WITH 12-LEAF FRONT SPRINGS
28
SPRING LEAFTO 389 320 04 02,5 225134-5 232113 FOR USE WITH 12-LEAF FRONT SPRINGS
28
SPRING LEAF , Replaced By: A6593210614
28
SPRING LEAF , Replaced By: A3463215614
32
SPRING LEAF , Replaced By: A3953210015
32
SPRING LEAFNO.7
32
SPRING LEAFNO.7
36
SPRING LEAFNO.8
36
SPRING LEAF , Replaced By: A3953210016
36
SPRING LEAF , Replaced By: A3463215616
40
SPRING LEAF , Replaced By: A6593210517
40
SPRING LEAF , Replaced By: A3463215617
40
SPRING LEAFNO.9
44
SPRING LEAFNO.10
44
SPRING LEAF , Replaced By: A3463215618
48
SPRING LEAF , Replaced By: A6593210519
48
SPRING LEAF , Replaced By: A3463215619
48
SPRING LEAFNO.11
52
SPRING LEAFNO.12
52
SPRING LEAF , Replaced By: A3463215620
56
SCREW (SPRING BOLT)
60
NUT STEERING SUPPORT TO FRAME
60
NUT , Replaced By: N910113014000
64
SPRING CLAMP , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A6553240033
64
SPRING CLAMP ,5 193394, Replaced By: A6203240733, +001N000963012011
64
SPRING CLAMP SPRING EYE,REAR,5 533058
68
SCREW FOR SPRING CLAMPS,5 484789
68
SCREW , Replaced By: N308765012007
72
NUT STRAP TO SUPPORT
76
WASHER FOR SPRING CLAMPS
80
U-BOLT FRONT SPRINGS TO FRONT AXLE 290 MM
80
U-BOLT FRONT SPRINGS TO FRONT AXLE 430 MM
80
U-BOLT FRONT SPRINGS TO FRONT AXLE 275 MM
80
U-BOLT FRONT SPRINGS TO FRONT AXLE 350 MM,5 906366
80
U-BOLT , Replaced By: A3043311925
80
U-BOLT , Replaced By: A3363310025
92
SHIM FRONT SPRINGS TO FRONT AXLE
92
SHIM FRONT SPRINGS TO FRONT AXLE
92
SHIM FRONT SPRINGS TO FRONT AXLE II
92
PAD FRONT SPRINGS TO FRONT AXLE
92
SHIM FRONT SPRINGS TO FRONT AXLE
92
SHIM FRONT SPRINGS TO FRONT AXLE
96
CENTERING BOLT FRONT SPRINGS TO FRONT AXLE 28 MM
96
PIN FRONT SPRINGS TO FRONT AXLE 28 MM, Replaced By: A9303230374
96
PIN , Replaced By: A6573310074
106
SHOCK ABSORBER , Replaced By: A0063230700
106
SHOCK ABSORBER , Replaced By: A0063230700
106
SHOCK ABSORBER , Replaced By: A0043234400
106
SHOCK ABSORBER , Replaced By: A0033239700
106
SHOCK ABSORBER
116
RUBBER MOUNTINGTO 003 326 46 00
116
RUBBER MOUNTINGTO 002 323 86 00,003 323 03 00,
116
RUBBER BUFFER SHOCK ABSORBER,BOTTOM TO 003 326 45 00, Replaced By: A0003238085
116
RUBBER BUFFER , Replaced By: A0003233144
116
RUBBER BUFFER , Replaced By: A0003232885
120
BUSHING , Replaced By: A0003233150
120
SPACER TUBE , Replaced By: A0003232550
120
SPACER RINGTO 002 323 86 00,003 323 03 00,
120
BUSHINGTO 004 323 52 00
999
SCREW FOR SPRING CLAMPS
999
PIN , Replaced By: A6573310074
999
U-BOLT FRONT SPRINGS TO FRONT AXLE 330 MM
