Поз.
Артикул
Описание
38
COMPRESSED AIR PIPE LEFT,656234
38
PIPE , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 935777, Replaced By: A4420101455
38
PIPE RIGHT,822458
38
COMPRESSED AIR PIPE LEFT,656336
38
PIPE RIGHT,828733
38
COMPRESSED AIR PIPE , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 656336, Replaced By: A4410100055
38
COMPRESSED AIR PIPE , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 656234, Replaced By: A4420100055
38
PIPE , Replaced By: A4420100355
38
PIPE LEFT,656337828733
38
PIPE LEFT,656235
38
PIPE RIGHT
41
BRACKET RIGHT,822457
44
BRACKET ,656235822457
47
BRACKET LEFT,656337
47
BRACKET LEFT,656336
50
HOLLOW SCREW COMPRESSED AIR PIPE TO CYLINDER HEAD 38 MM
50
HOLLOW SCREW COMPRESSED AIR PIPE TO CYLINDER HEAD,828734
53
SEAL RING COMPRESSED AIR LINE TO PARKING BRAKE VALVE
53
SEAL , Replaced By: N007603012106
59
NUT , Replaced By: N308675014001
59
NUT JOINT TO BRACKET
59
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
71
FITTING LINE CONNECTIONS,4 412125
71
FITTING COMPRESSED AIR LINE CONNECTION,656235822457
71
T-FITTING 3/2-WAY VALVE,CONNECTION: "33", UP TO IDENT NO. 5 385481 FROM IDENT NO. SEE STANDARD VERSION
71
FITTING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4420100078, +001A4420161032
74
PIPE , Replaced By: A4410100355
74
PIPE , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 935777, Replaced By: A4420101255
74
PIPE , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 935777, Replaced By: A4420101355
74
PIPE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4420161032, +001A4420100078
74
PIPE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4420161132
74
PIPE , Replaced By: A4420100655
74
PIPE COMPRESSED AIR LINE,828733
74
PIPE COMPRESSED AIR LINE,656235822457
74
PIPE RIGHT,656235822457
74
PIPE LEFT,822458
74
PIPE COMPRESSED AIR LINE,656336
74
PIPE RIGHT,822458
83
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
86
SLEEVE LINE CONNECTION
89
GLAND LINE CONNECTION
92
UNION NUT LINE CONNECTION
95
CLAMP BATTERY CABLE MOUNTING
95
CLAMP , Replaced By: N916016008200
95
CLAMP , Replaced By: A3604300143
98
SCREW ,K 062140, Replaced By: N007985006580
98
SCREW , Replaced By: N000000001146
98
SCREW APPARATUS PLATE TO CAB,K 062140
98
SCREW CLAMP MOUNTING M 6X16
98
SCREW CLAMP TO EXHAUST PIPE AND TO FLEXIBLE METAL TUBE M 8X25
101
WASHER RADIATOR TO RUBBER MOUNTING
104
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
104
NUT BALL PIVOT TO LEVER
110
LOOM TIE LINE MOUNTING 280 MM
999
CLAMP DE-AERATION LINE TO CAB
999
BRACKET COMPRESSED AIR PIPE TO CONNECTION FLANGE, BOOST AIR PIPES,822458
999
CYLINDER HEAD , 402 266250 421-422 171870
999
PIPE , Replaced By: A4410100655
999
PIPE , Replaced By: A4410100755
999
PIPE RIGHT AND LEFT,828734
999
PIPE COMPRESSED AIR LINE,828734
999
FITTING COMPRESSED AIR LINE CONNECTION,822458
999
SEAL RING , THE OLD PART MUST NO LONGER BE INSTALLED635203, Replaced By: A5410160290
999
PISTON ,635202, Replaced By: A4420160290, +001A4420160063
999
PIPE COMPRESSED AIR LINE
999
PIPE COMPRESSED AIR LINE
999
BANJO UNION COMPRESSED AIR PIPE TO CYLINDER HEAD
