Поз.
Артикул
Описание
5
CRANKCASE
5
CRANKCASE , Replaced By: A5420102305
8
DOWEL PIN CRANKSHAFT BEARING CAP
14
CYLINDRICAL PIN
23
CAMSHAFT BEARING WITH COLLAR,*0398198
23
CAMSHAFT BEARING WITH COLLAR,*0398199*0460636
26
CAMSHAFT BEARING STANDARD,*0378690*0460636
26
CAMSHAFT BEARING STANDARD,*0460637
32
SCREW PLUGTO 000 553 03 05,000 553 18 05,
32
SCREW PLUG FUEL TANK
35
SEALING RING
38
OIL NOZZLE LUBRICATION OF P.T.O.
41
SEALING RING OIL LINE TO CYLINDER CRANKCASE
44
SCREW PLUG IN PLACE OF SPEEDOMETER DRIVE
47
SEALING RING ,760252
50
SCREW PLUG IN PLACE OF SPEEDOMETER DRIVE
53
SEALING RING ,760252
56
CAP TO PLUG CORE HOLES 34.2
56
EXPANSION PLUG TO PLUG CORE HOLES 34.2, Replaced By: N000000004057
56
EXPANSION PLUG WATER PASSAGE
56
EXPANSION PLUG WATER PASSAGE,REAR 54.00 MM,*0036124
59
SCREW PLUG OIL COOLER,5 360280
62
SEAL RING
65
CYLINDRICAL PIN FRONT COVER FIXING 8X24
68
CYLINDRICAL PIN TIMING CASE FIXING 16X24
71
BALL FRONT AND REAR 14.288 MM
71
BALL SHIFTING CYLINDER
71
BALL HOUSING,TOP
71
BALL TO PLUG OIL CONNECTION TO AIR COMPRESSOR
71
BALL , UP TO CHASSIS 447270 FROM CHASSIS SEE SPARE PARTS LIST 817,INAPPLICABLE TO R.H.D.AND SUPERCHARGED ENGINE VEHICLES
71
BALL BEARING
110
COVER
110
COVER CYLINDER CRANKCASE,FRONT
110
COVER CYLINDER CRANKCASE,FRONT
114
GUIDE SLEEVE COVER TO CYLINDER CRANKCASE,FRONT,*0850654
116
SEAL RING CRANKSHAFT SEALING,FRONT, RECOMMENDED FOR TAKING ON STOCK USE THIS SEALING RING FOR NORMAL REPAIR, Replaced By: A0159974746
116
SEAL RING , Replaced By: A0259973947
116
RADIAL SHAFT SEALING RING CRANKSHAFT SEALING,FRONT, USE THIS SEALING RING FOR NORMAL REPAIR RECOMMENDED FOR TAKING ON STOCK
116
RADIAL SHAFT SEALING RING CRANKSHAFT SEALING,FRONT
116
SEAL RING CRANKSHAFT SEALING,FRONT,708527 ONLY USE FOR HEAVY GROOVES AND SCORE MARKS AND HEAVY GROOVES ONCRANKSHAFT JOURNAL. INSTALL SEALING RING TOGETHER WITH RACE A 442 031 00 27 I.D., 105MM
119
GASKET COVER TO CYLINDER CRANKCASE,FRONT, AS OF ENGINE 288416
122
HEXAGON HEAD BOLT. SCREW BRACKET TO TRANSMISSION M 10X50
122
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
122
HEXAGON HEAD BOLT. SCREW BRACKET TO AIR INTAKE PIPE M 10X45
122
HEXAGON HEAD BOLT AUTOMATIC TRANSMISSION AT ENGINE M10X60
122
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
125
OIL NOZZLE
128
SCREW STOP TO BATTERY CASE
130
PRESSURE RELIEF VALVE NON-RETURN OIL VALVE
131
VALVE ,*0000175*0012317
131
VALVE ,*0000174, Replaced By: A5411840332
134
SCREW PLUG NON-RETURN OIL VALVE
137
SEAL RING NON-RETURN OIL VALVE, I.D. 19 MM
140
SPRING (BY-PASS VALVE)
146
SEALING RING NON-RETURN OIL VALVE
149
SENDER UNIT TEMPERATURE SENDER UNIT
149
SENDER UNIT TEMPERATURE GAUGE SENDER UNIT
152
SEALING RING
182
GASKET KIT CYLINDER CRANKCASE, RECOMMENDED FOR TAKING ON STOCK
185
TYPE PLATE , STATE ENGINE NO.AND CHASSIS NO.WHEN ORDERING
188
RIVET ENGINE PLATE TO ENGINE
