Поз.
Артикул
Описание
5
GLOVE COMPARTMENT , FROM CHASSIS 107.042 011913 107.045 009957 107.046 001109 TO BE ADAPTED DURING ASSEMBLY
5
GLOVE COMPARTMENT , Replaced By: A1076891791, +001A1076891108
8
GLOVE COMPARTMENT LID , FOR COLOR AND CODE NOS.,SEE PASSENGER CAR EQUIPMENT MANUAL UP TO CHASSIS NEW EQUIPMENT 7/75 022 001021 023 010496 024 010755 EXCEPT FOR 010745-010754 042 000843 043 012033 044 027279 EXCEPT FOR 027268,027277
14
SHEET METAL SCREW FRONT FENDER TO BRACKET AT FRONT LATERAL STIFFENING
17
HINGE
20
LOCK , FROM CHASSIS: 010 012069 110 026452
20
LOCK , FROM CHASSIS: 010 012069 110 026452
23
SHEET METAL SCREW , Replaced By: N000000000453
26
WASHER , Replaced By: N000125004319
35
COVERING GLOVE COMPARTMENT,A 045176
38
RIVET
41
FASTENER WITH KEY
44
FASTENER LESS KEY, STATE LOCK NUMBER WHEN ORDERING
47
SCREW SLOTTED GATE
50
SPRING
53
KNOB
56
STRIKER
59
LOCK
62
SHEET METAL SCREW CONSOLE TO TUNNEL PANELLING,FRONT
65
STOP LEFT
65
STOP RIGHT
71
SCREW
74
SPRING WASHER LICENSE PLATE TO BRACKET
