Поз.
Артикул
Описание
5
CONTROL UNITTEMPOMAT
8
SHEET METAL SCREW CONTROL UNIT TO BRACKET
14
BRACKET
20
SCREW CAB FLOOR COVERING M 6X25
32
CONTROL UNIT ACTUATOR
35
BRACKET AT WHEEL ARCH
38
NUT CYLINDER TO BRACKET TO0002902112
38
NUT BATTERY MOUNTING
41
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
44
NUT
45
SPRING WASHER , Replaced By: N000137008212
47
LOCK FOR BOWDEN CABLE CLIP
50
WIRE CABLE
53
SHEET METAL SCREW MODULE TO HOUSING
53
SHEET METAL SCREW REFLECTOR TO BUMPER
71
HOSE1150 MM, ORDER BY THE METER
77
HOSE AERATION 900 MM
83
BRANCH-OFF FITTING
86
HOSE *** 30 MM
89
NUT
