Поз.
Артикул
Описание
4
FUEL TANK 82 L.
6
REINFORCEMENT , Replaced By: A1304710222
6
REINFORCEMENT
8
GASKET
10
SPRING WASHER CABLE TO ALTERNATOR
10
SPRING WASHER ALTERNATOR CONNECTION D+
12
NUT
12
NUT TACHOGRAPH TO BRACKET
14
FUEL STRAINER
14
FUEL STRAINER , Replaced By: A1114700686
16
SEAL RING , Replaced By: A1109970145
16
SEAL RING
18
GAUGE SENDER UNIT
18
GAUGE SENDER UNIT , Replaced By: A1105421204
20
BASE FRONT
22
BRACKET
24
RUBBER BUFFER
26
BRACKET TANK FRONT BRACING
28
CLAMP , 000,001,010 FROM CHASSIS 130558, 100,101,110 FROM CHASSIS 225648
32
WASHER , Replaced By: N009021006208
32
WASHER COMPRESSED AIR LINE TO BRACKET
34
WASHER PROTECTIVE PLATE TO BRACKET,5 502998
34
WASHER BRACKET TO CAB REAR PANEL
34
WASHER , Replaced By: A0039902940
36
LOCK WASHER TAIL LAMP TO BRACKET
36
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
38
NUT BATTERY CASE
38
NUT
40
FILLER CAP MAKE YMOS YMOS, STATE LOCK NUMBER WHEN ORDERING UP TO CHASSIS:012 058944,014 045196,015 002591
42
GASKET
42
GASKET , Replaced By: A1104710280
44
BOOT
46
LOCKING CAP TRANSMISSION OIL LEVEL CHECK, 000,001,004,010 UP TO CHASSIS 074402,100,101,104,110 UP TO CHASSIS 116802
46
LOCKING CAP
48
TANK , Replaced By: A1154710268, +001A0029884678
48
TANK , 012 UP TO CHASSIS 058520, 014 UP TO CHASSIS 045547, Replaced By: A1154710268, +001A0009903533, +001A1109950332, +001N000127004203, +001N000934004000, +001N007981004240, +001N072571002015
48
TANK , 012 UP TO CHASSIS 058520, 014 UP TO CHASSIS 045547, 015 UP TO CHASSIS 002626, Replaced By: A1154710268, +001A0009903533, +001A1109950332, +001N000127004203, +001N000934004006, +001N007981004240, +001N072571002015
48
TANK
50
CLIP
50
CLIP ELECTRIC CABLE MOUNTING
52
HOSE , Replaced By: A2014761126
52
HOSE4.5X10X900MM
54
GROMMET
56
BOOT
56
BOOT , Replaced By: A1114710181
56
BOOT , Replaced By: A1114710181
58
CLAMP , 012 FROM CHASSIS 058521, 014 FROM CHASSIS 045548, 015 FROM CHASSIS 002627
140
LINE RETURN,042 013015
142
HOSE DE-AERATION B8X12,5 218304 ORDER BY THE METER
142
HOSE , Replaced By: A1149971882
999
CLAMP
999
CLAMP LINE CONNECTION
999
CLAMP LINE MOUNTING
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
LOCK WASHER T-FITTING TO BRACKET
999
CLAMP
999
CLAMP FROM RADIATOR TO TANK
999
CLAMP , 018 FROM CHASSIS 030632, 019 FROM CHASSIS 030489
999
CLAMP
999
NUT BATTERY MOUNTING
999
SCREW COVER PLATE TO COVER PLATE M 6 X 10
999
HOSE , ORDER BY THE METER
999
SCREW
999
SHEET METAL SCREW , Replaced By: N000000002062
999
SHEET METAL SCREW WIRE CABLE TO CAB
999
SHEET METAL SCREW BRACKET TO CAB FLOOR, EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 5 180559
999
NUT CYLINDER TO BRACKET TO0002902112
999
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
999
NUT AIR INTAKE PIPE TO AIR INTAKE PIPE,937184
999
SCREW COVER PLATE TO BRACKET
999
SCREW , Replaced By: N304017006034
999
LOCK WASHER. SPRING LOCK WASHER ELECTRIC CABLE TO HORN TO 004 542 44 20 /45 20
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
WASHER , UP TO CHASSIS: 017 029988 114 000523 117 064694
999
SCREW FUEL AND BRAKE LINES TO FRAME FLOOR UNIT
999
SCREW
999
CLAMP , Replaced By: A1109950401
999
HOSE , FOR THE NEW PART,SEE GROUP 07, Replaced By: A1270101132, +001A0000741084, +001A0000741386, +002N007603014100, +001N007623008101
999
BUFFER
999
HOSE , Replaced By: A1149971882, +NBA0019976990
999
DAMPING STRIP FUEL AND BRAKE LINES TO FRAME FLOOR UNIT, 016 UP TO CHASSIS 035213 EXCEPT FOR, SEE FOOTNOTE 29, 018,019 UP TO CHASSIS 036080 EXCEPT FOR, SEE FOOTNOTE 30
999
CLAMP FUEL LINE TO BRACKET
999
CLAMP , 116.020 071390 ALSO INSTALLED ON 071392,071396,071400,071402,071416. 116.024,025 068051 ALSO INSTALLED ON 068099,068265 EXCEPT FOR 055714,055888,057629,058694,066624,066628,066632,066803,067088,067089,067410,067542,067578-067580, 067860-067862,067865,067924,067928-067943,067945,067948,067952,067953,067955-067969,067971-068001, 068005,068007-068019,068024,068026-068029,068031-068033,068035-068048,068050.
999
CLAMP FORKED SUPPORT,TOP
999
HOSE CLAMP HOSE FASTENING 9/13MM
999
FUEL PUMP , Replaced By: A0010915201, +001A1084700281, +003A1269880011, +001N000127005203, +003N000127006203, +003N000933006016, +003N000934005004
999
FUEL PUMP , Replaced By: A0010913401
999
GROMMET TACHOGRAPH OR SPEEDOMETER
999
FILLER CAP , STATE LOCK NUMBER WHEN ORDERING010356
