Поз.
Артикул
Описание
5
PARKING BRAKE
8
SPRING
11
HOSE25 MM, ORDER BY THE METER
14
DAMPING RING
17
PAD
20
SCREW LEVER TO ENGINE CONTROL SHAFT
20
SCREW , Replaced By: N910105006023
23
COMBINATION BOLT INSTRUMENT PANEL TO FRONT PANEL PILLAR
23
SCREW PUMP TO BRACKET
26
CHAIN PULL
29
GUIDE
32
SCREW BATTERY CABLE MOUNTING AND MAIN CABLE HARNESS MOUNTING
35
COVERING
146
LOOM TIE LINE MOUNTING 280 MM
146
LOOM TIE LINE MOUNTING 150 X 3,6 MM
149
BRAKE CABLE FRONT
155
SPRING
158
HOSE30 MM, ORDER BY THE METER
161
CLAMP FORKED SUPPORT,TOP
164
SHEET METAL SCREW VALVE TO WINDOW SILL
167
SPRING
170
SPACER TUBE BRAKE CABLE TO REAR FLOOR
173
SHACKLE
176
SCREW , Replaced By: N304017008027
179
PIN BRAKE CABLE TO INTERMEDIATE LEVER
182
COTTER PIN ROLLER TO LEVER
185
SPRING
188
BRAKE CABLE REAR LEFT
191
BRAKE CABLE REAR RIGHT
194
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
194
SCREW , Replaced By: N000933010162
197
COMBINATION BOLT BRAKE CABLE TO REAR AXLE
200
SPRING WASHER SHIFTING ROD TO BRACKET
203
GROMMET BRAKE CABLE TO REAR AXLE
206
SPRING
