Поз.
Артикул
Описание
5
FUEL TANK
5
FUEL TANK , Replaced By: A1264703401
26
FUNNEL , Replaced By: A1694700029
29
GAUGE SENDER UNIT
32
SEAL RING FUEL GAUGE SENDER UNIT TO FUEL TANK
35
FUEL STRAINER PARTS KIT
38
SEAL RING
41
REINFORCEMENT FUEL TANK,RIGHT
41
REINFORCEMENT FUEL TANK,LEFT
44
WASHER PROTECTIVE PLATE TO BRACKET,5 502998
47
NUT
47
NUT , Replaced By: N304032008006
50
GROMMET , Replaced By: A1239973581
50
GROMMET , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 021 001206 022,023 047750 032,033 022999 036,037 015144, Replaced By: A1239973581
50
GROMMET FILLER NECK THRU FENDER RECESS
56
FILLER CAP , Replaced By: A1244700005
56
FILLER CAP , Replaced By: A1244700005
56
FILLER CAP , Replaced By: A0004700730
59
SEAL RING
