Поз.
Артикул
Описание
20
DIFFERENTIAL GEAR LESS RING GEAR AND PINION
20
DIFFERENTIAL GEAR , Replaced By: A1243506323
23
THRUST WASHER AS REQUIRED 1,25 MM
23
THRUST WASHER AS REQUIRED 1,45 MM
23
THRUST WASHER AS REQUIRED 1.6 MM
23
THRUST WASHER AS REQUIRED 1,5 MM
23
THRUST WASHER AS REQUIRED 1,35 MM
23
THRUST WASHER AS REQUIRED 1,55 MM
23
THRUST WASHER AS REQUIRED 1,4 MM
23
THRUST WASHER AS REQUIRED 1,3 MM
23
THRUST WASHER AS REQUIRED 1,65 MM
26
SIDE GEAR
29
DIFFERENTIAL PINION
32
SPHERICAL WASHER
35
PIN
38
CLAMPING SLEEVE
41
RING GEAR AND PINION1:3.07
44
GEAR 31 TEETH
47
SCREW RING GEAR TO DIFFERENTIAL CASE
47
SCREW , Replaced By: A2029902801
50
TAPERED ROLLER BEARING RING GEAR BEARING, REAR AXLE HOUSING WITH DIFFERENTIAL,LESS SIDE BEARING CABS 003 103239 007 087551 086 007106 093 008992 102,103 240183 105 231729 183 015395 190 021957 193 002093 200 027295 280 000777 283 003632
68
SPACER WASHER AS REQUIRED 1.7 MM
68
SPACER WASHER AS REQUIRED 1.6 MM
68
SPACER WASHER AS REQUIRED 1.8 MM
68
SPACER WASHER AS REQUIRED 1.5 MM
71
TAPERED ROLLER BEARING
74
SPACER BUSHING
77
TAPERED ROLLER BEARING DRIVE PINION BEARING
77
TAPERED ROLLER BEARING , Replaced By: A0029801102
80
FLANGE PROPELLER SHAFT
80
FLANGE , Replaced By: A2113500045, +002A0229979947
80
FLANGE , Replaced By: A1243506845
83
SEAL RING , Replaced By: A0259970047
83
SEAL RING , Replaced By: A0229979947
83
SEAL RING , Replaced By: A0209972147
83
SEAL RING DRIVE PINION
86
NUT , FROM CHASSIS: 007,008,015,017 219403 011 104138 060 107834 062 104361
