Поз.
Артикул
Описание
5
RAIL REAR DOOR,BOTTOM RIGHT
5
RAIL REAR DOOR,BOTTOM LEFT
6
SHEET METAL SCREW
8
END PIECE FRONT BOTTOM LEFT
8
END PIECE FRONT BOTTOM RIGHT
11
RAIL REAR DOOR,TOP RIGHT
11
RAIL REAR DOOR,TOP LEFT
14
END PIECE FRONT TOP RIGHT
14
END PIECE FRONT TOP LEFT
17
SCREW
20
WASHER BRACKET TO SUPPORT
23
NUT ANTENNA COMBINER TO COVERING
26
LOCK. SHEET METAL NUT PLATE TO FRAME,V 202043
29
SHEET METAL SCREW TOP COVERING IN HOUSING B 4,2X16
32
SCREW VOLTAGE TRANSFORMER TO MOUNTING PLATE
38
SCREW
41
CURTAIN RIGHT REAR SIDE WINDOW
41
CURTAIN LEFT REAR SIDE WINDOW
41
CURTAIN , Replaced By: A1408103823
41
CURTAIN , Replaced By: A1408103723
44
RING
47
HOOK
50
SLIDE
53
CLIP FOR DETENT
56
CURTAIN REAR WINDOW, LEFT
57
CURTAIN REAR WINDOW,RIGHT
59
RING
62
HOOK
65
RING
68
RAIL AT HAT TRAY
71
PLATE RAIL TO REAR DOOR COVERING
71
PLATE RAIL TO ROOF COVERING
74
WASHER , Replaced By: N000433005304
74
WASHER BRACKET TO SUPPORT
77
NUT RELAY TO BRACKET M5
77
NUT , Replaced By: N913023005002
77
NUT ANTENNA COMBINER TO COVERING
80
PAD
83
TUBE REAR WINDOW,RIGHT
83
TUBE REAR WINDOW, LEFT
86
CURTAIN PULL TOP
86
CURTAIN PULL BOTTOM
89
CLAMP ,B 926099
92
RAIL REAR ROOF RAIL
98
BRACKET MOTOR TO TOP PANELLING
107
LOCK
110
SHEET METAL SCREW BRACKET TO FIRE WALL
999
BRACKET PIPE TO PANELLING
999
BRACKET PIPE TO PANELLING
999
COVERING RIGHT
999
INSERT REAR BOTTOM
999
COVERING LEFT
999
INSERT REAR TOP
999
ANGLE RAIL TO ROOF COVERING
