Поз.
Артикул
Описание
5
BRACKET SOLENOID VALVE
5
BRACKET NOZZLE HOLDER
5
BRACKET NOZZLE HOLDER
5
BRACKET NOZZLE HOLDER
5
BRACKET , Replaced By: A4220780741
5
BRACKET , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 648782, Replaced By: A4420782741
5
BRACKET , Replaced By: A4420784341
5
BRACKET , Replaced By: A4420784441
5
BRACKET NOZZLE HOLDER, Replaced By: A5410700840
5
BRACKET NOZZLE HOLDER
8
VALVE , Replaced By: N915036010100
8
VALVE (OVERFLOW VALVE)
11
CONNECTOR NOZZLE HOLDERS
11
CONNECTOR NOZZLE HOLDERS
11
BRACKET NOZZLE HOLDER
11
BRACKET NOZZLE HOLDER
11
BRACKET NOZZLE HOLDER, Replaced By: A5410700840
17
VALVE , Replaced By: A0000783649
17
VALVE , Replaced By: A0000784549
17
VALVE (ELECTROMAGNET VALVE)
20
BRACKET ELECTROMAGNET VALVE
20
BRACKET ELECTROMAGNET VALVE
23
HEXAGON HEAD BOLT BRACKET TO TRANSMISSION
23
SCREW BRACKET TO TRANSMISSION
23
SCREW , Replaced By: N308676012038
26
BRACKET COMPRESSED AIR ELBOW
26
BRACKET ELECTRIC CABLE TO OIL PAN
29
BRACKET TWO-WAY VALVE
32
CLAMP FROM DISTRIBUTOR TO CYLINDER
32
CLAMP HYDRAULIC LINE TO SIDE MEMBER,RB012797
32
CLAMP SENSOR CABLE TO FRONT AXLE
35
WASHER COVER TO ALTERNATOR
38
HEXAGON HEAD BOLT. SCREW BATTERY MOUNTING M5X12
38
SCREW STOP TO BATTERY CASE
38
SCREW CLAMP MOUNTING M 6X16
38
HEXALOBULAR BOLT. SCREW SUPPORT TO CYLINDER HEAD
38
SCREW , Replaced By: N914146006102
38
HEXAGON HEAD BOLT. SCREW CABLE HARNESS TO BRACKET M8X40
41
NUT , Replaced By: N304032005005
41
NUT , Replaced By: N913023006001
41
HEXAGON NUT. NUT , Replaced By: N913023008002
41
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
41
NUT IN CASE OF SUBSEQUENT INSTALLATION
65
NOZZLE FLAME STARTING SYSTEM
65
NOZZLE
65
NOZZLE FLAME STARTING SYSTEM
65
NOZZLE FLAME START SYSTEM
65
NOZZLE
68
SEAL ELECTROMAGNET VALVE
68
SEAL , Replaced By: A4420780280
71
SCREW. HEXAGON HEAD BOLT BATTERY CABLE M6X50
71
SCREW. HEXAGON HEAD BOLT BATTERY AND ENGINE CABLE HARNESSES TO BRACKET M6X35
71
SCREW HYDRAULIC LINE TO SIDE MEMBER
71
HEXALOBULAR BOLT. SCREW CLAMP ON BRACKET M 6X35
71
SCREW HOUSING TO BRACKET
71
SCREW DISTRIBUTOR TO CAB
74
SPRING WASHER COVER TO THERMOSTAT HOUSING, ELIMINATED NO LONGER REQUIRED
74
SPRING WASHER LICENSE PLATE TO BRACKET
77
GLOW PLUG , Replaced By: A0011590701
77
GLOW PLUG
77
GLOW PLUG24 V
77
HEATER PLUG
83
BURNER
83
FLOAT CHAMBER
83
BURNER , Replaced By: A4420700186
83
BURNER , Replaced By: A5420700086
107
SEAL , Replaced By: A4420780180
107
SEAL TO LOCK THE BORE MEANT FOR FLAME START SYSTEM
110
SCREW STOP TO BATTERY CASE
110
SCREW SUPPORT TO SIDE MEMBER
116
LINE FUEL LINE
116
PLASTIC PIPE RISING PIPE 4X6 MM
116
HOSE FROM WARNING INDICATOR TO AIR CLEANER, ORDER BY THE METER
137
BANJO UNION , Replaced By: N915052004004
137
BANJO UNION HOSE WIDTH, / I.D., 4/10 MM
137
BANJO UNION
137
BANJO UNION AXLE BREATHING 4/8
137
BANJO UNION FROM INJECTION PUMP TO VALVE
137
BANJO UNION HOSE WIDTH, / I.D., 4/16 MM,5 999999K 040105
140
SCREW PLUG ,819969
140
SCREW PLUG , Replaced By: N007604014110
143
HOLLOW SCREW , Replaced By: N915036010109
143
HOLLOW SCREW FUEL LINES TO SOLENOID VALVE
143
HOLLOW SCREW COMPRESSED AIR LINE TO OPERATING CYLINDER
143
HOLLOW SCREW FUEL LINE LEADING TO FUEL PUMP
143
HOLLOW SCREW HAND PUMP,K 169122
152
SEAL RING SCREW PLUG
152
SEAL RING , Replaced By: N007603010110
173
HOLLOW SCREW FUEL LINE LEADING TO FUEL PUMP
173
HOLLOW SCREW FUEL LINE LEADING TO FUEL PUMP
173
HOLLOW SCREW FUEL-FILTER-TO-INJECTION-PUMP LINE
176
SEAL RING INJECTION PUMP
176
SEAL RING SCREW PLUG
179
LINE FUEL LINE 5X1 MM,807206
179
LINE FUEL LINE 5X1 MM
179
LINE FUEL LINE 5X1 MM
179
LINE FUEL LINE 5X1 MM
179
LINE FUEL LINE 5X1 MM,807205
179
LINE FUEL LINE 5X1 MM
179
LINE , Replaced By: A4410700435
179
LINE , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 735943, Replaced By: A4420709432
179
LINE (CONNECTING LINE)
182
LINE FROM INJECTION PUMP TO INTERMEDIATE PIECE
182
LINE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4420700135
185
BANJO UNION
188
SEAL CONE
191
UNION NUT
194
FITTING
197
LINE FUEL LINES TO SOLENOID VALVE, NOT USED
200
BANJO UNION
203
SEAL CONE
206
UNION NUT
209
CLAMPING PIECE
209
CLAMPING PIECE , ELIMINATED,NO LONGER REQUIRED
212
CLAMP , FROM ENGINE 461719 YEAR OF MANUFACTURE 1998, Replaced By: A0009951407
212
CLAMP , Replaced By: A4229950122
215
CLAMP SENSOR CABLE TO FRONT AXLE
218
SHIM , Replaced By: A4030780486
218
SHIM , Replaced By: A4220780386
218
SHIM , 340.930 FROM ENGINE 084456
221
SCREW BRACKET ON LOAD SENSOR
221
SCREW , Replaced By: N304017006018
221
SCREW COVER PLATE TO COVER PLATE M 6 X 12
221
HEXAGON HEAD BOLT
224
NUT , Replaced By: N913023006001
224
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
227
THREADED UNION FUEL LINE TO CHARGING AIR INTERCOOLER
230
SWITCH,AUTOMATIC TEMPERATURE
230
SWITCH,AUTOMATIC TEMPERATURE SWITCH
230
SWITCH,AUTOMATIC , Replaced By: A0075455224
230
SENDER UNIT , Replaced By: A0065457524
293
BRACKET FUEL LINE TO CHARGING AIR PIPE,733620
296
BRACKET FUEL LINE TO CHARGING AIR PIPE,733620
296
ANGLE LINE MOUNTING
296
BRACKET FUEL LINE TO INTAKE MANIFOLD,803666
299
BRACKET FUEL LINE TO INTAKE MANIFOLD,733620
299
BRACKET FUEL LINE TO CHARGING AIR PIPE
302
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT, TO BE ADAPTED DURING ASSEMBLY
305
SPACER TUBE FUEL LINE TO INTAKE MANIFOLD
305
SPACER TUBE SUPPORT TO INTAKE PIPE
308
CLAMP BATTERY CABLE TO CROSS MEMBER
308
CLAMP FROM DISTRIBUTOR TO CYLINDER
308
CLAMP CABLE HARNESS MOUNTING
308
CLAMP HYDRAULIC LINE TO SIDE MEMBER,RB012797
308
CLAMP , Replaced By: N916016010211
308
CLAMP , Replaced By: N000000001045
308
CLAMP SENSOR CABLE TO FRONT AXLE
311
SCREW CLAMP MOUNTING M 6X16
311
SCREW , Replaced By: N914146006102
311
HEXAGON HEAD BOLT. SCREW CABLE HARNESS TO BRACKET M8X40
311
COMBINATION BOLT , Replaced By: A0079902001
311
HEXAGON HEAD BOLT. SCREWM 12X1,5X20 MM - TO A 202 490 08 41
311
SCREW STOP TO BATTERY CASE
311
SCREW WIRING HARNESS FIXTURE AT AIR PIPE
311
SCREW TWO-WAY VALVE TO BRACKET
311
SCREWM 8X125, FROM ENGINE 706242-999999 YEAR OF MANUFACTURE 1982-1990 FROM ENGINE 100001 YEAR OF MANUFACTURE 1990
311
SCREW FUEL LINE TO INTAKE MANIFOLD M 8X98
311
HEXALOBULAR BOLT. SCREW SUPPORT TO CYLINDER HEAD
311
HEXAGON HEAD BOLT. SCREW BATTERY MOUNTING M5X12
314
SPRING WASHER ALTERNATOR CONNECTION D+
314
WASHER BRACKET TO WINDOW SILL
314
WASHER REDUCTION GEARING TO BRACKET
314
WASHER COVER TO ALTERNATOR
314
WASHER FROM TERMINAL BOX TO CHARGING AIR PIPE
314
WASHER SUPPORTING RAIL TO SUPPORT,5 429712
314
WASHER BOOT TO CAB FLOOR
314
WASHER , Replaced By: N000433005304
317
HEX. NUT M 5 DIN 934-5 S. NUT PLUG SOCKET TO FRAME
317
NUT , Replaced By: N304032005005
317
NUT , Replaced By: N913023006001
317
NUT IN CASE OF SUBSEQUENT INSTALLATION
317
HEXAGON NUT. NUT , Replaced By: N913023008002
317
NUT RELAY TO BRACKET M5
317
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
317
HEXAGON HEAD BOLT. SCREW BATTERY MOUNTING M5X12
320
HEXAGON HEAD BOLT. SCREW BATTERY MOUNTING M5X12
320
SCREW FUEL LINE TO INTAKE MANIFOLD
320
SCREW BOWDEN CABLE TO BRACKET
320
SCREWM 8X125, FROM ENGINE 706242-999999 YEAR OF MANUFACTURE 1982-1990 FROM ENGINE 100001 YEAR OF MANUFACTURE 1990
320
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL M8X16 MM
320
SCREW. HEXAGON HEAD BOLT RELAY TO BRACKET M5X16
320
SCREW , Replaced By: N304017005002
320
SCREW LEVER TO SHAFT
320
SCREW , Replaced By: N914146006102
320
SCREW CLAMP MOUNTING M 6X16
323
SENDER UNIT FLAME STARTING SYSTEM PRE-GLOW INDICATOR
326
THREADED UNION TEMPERATURE GAUGE SENDER UNIT
999
VALVE HOLLOW SCREW,082519
999
VALVE (ELECTROMAGNET VALVE) 24 V
999
PARTS KIT TWO PIN JACK CONNECTOR
999
BRACKET FILLER NECK,4 400466
999
HOLLOW SCREW FUEL LINE TO FEED PUMP
999
FLANGE TO LOCK THE BORE MEANT FOR FLAME START SYSTEM
999
LINE FROM INJECTION PUMP TO VALVE 700 MM
999
BURNER , NOT USED
999
LINE FUEL LINE TO ELECTROMAGNETIC VALVE
999
LINE FROM ELECTROMAGNETIC VALVE TO HEATER PLUG,RIGHT, NOT USED
999
LINE FROM ELECTROMAGNETIC VALVE TO HEATER PLUG,LEFT
999
BRACKET ELECTROMAGNET VALVE, NOT USED
999
LINE5X1X1100, NOT USED
