Поз.
Артикул
Описание
15
BEARING BRACKET PEDAL ASSEMBLY
15
BEARING BRACKET
40
PEDAL
40
PEDAL CLUTCH, 035692 901874
44
BUSHING BRAKE PEDAL
52
BUSHING
58
PAD , Replaced By: A1072910182
58
PAD BRAKE
62
BRACKET
65
SCREW PIPE CLAMP
65
SCREW , Replaced By: N304017008021
66
SPRING WASHER , Replaced By: N000137008212
66
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
72
NUT SHIFT LEVER HANDLE TO SHIFT LEVER
76
BUSHING APPARATUS PLATE 9 MM, TO BE ADAPTED DURING ASSEMBLY
80
SPRING RETAINER SPRING TO PUSH ROD
84
SPRING CLUTCH PEDAL RESET
88
SPRING RETAINER SPRING TO PUSH ROD
108
PEDAL BRAKE, 035692 901874
108
PEDAL
112
BUSHING , Replaced By: A1242920050
116
BUSHING
120
PAD BRAKE
120
PAD , Replaced By: A1072910182
126
SPINDLE BRAKE PEDAL
128
SPINDLE CLUTCH PEDAL
150
BRACKET CLUTCH RESERVOIR
162
SCREW CAB FLOOR COVERING M 6X25
164
NUT BALL PIVOT TO LEVER
168
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
228
RIVET , Replaced By: A1239900592
228
RIVET ON CAB FLOOR UNDER STEP
246
STOP STOP LIGHT SWITCH
