Поз.
Артикул
Описание
48
BEARING BODY FAN DRIVE TO 373 205 73 02
50
SCREW PLUG 4/2-WAY VALVE
50
SCREW PLUG AIR DEHYDRATOR
53
SEAL RING , Replaced By: N007603010110
56
SCREW , Replaced By: N304017008053
56
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL
59
WASHER , Replaced By: N000125008443
62
NUT , Replaced By: N913004008001
62
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
65
FAN SHAFT FAN DRIVE TO 373 205 73 05
68
LOCK RING
68
LOCK RING52X2 MM
70
GROOVED BALL BEARING
74
CYLINDR. ROLLER BEARING FAN DRIVE
74
CYLINDR. ROLLER BEARING ON RADIATOR SIDE
77
SEAL RING CASE COVER
80
HUB POWER SAVER FAN
86
LOCK WASHER TRANSMISSION TO BELL HOUSING
89
NUT HUB TO FAN SHAFT
98
PULLEY FAN DRIVE 180 MM
98
PULLEY FAN DRIVE
101
HUB HUB TO FAN DRIVE
104
SCREW , Replaced By: N304017008027
104
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
107
NUT , Replaced By: N913004008001
107
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
110
WASHER , Replaced By: N000125017016
110
WASHER BRACKET TO FRAME
119
NUT , Replaced By: N910113016001
119
NUT CONSOLE TO SUPPORT
149
SUPPORT CLAMPING LEVER
152
STUD SUPPORT TO FAN SUPPORT
155
NUT STRAP TO SUPPORT
158
SCREW RADIATOR M 10X45
161
WASHER , Replaced By: N000125010532
161
WASHER RADIATOR TO RUBBER MOUNTING
164
WASHER , Replaced By: N009021010209
164
WASHER BRACKET TO COVERING
167
NUT , Replaced By: N910113010000
170
LEVER BELT TIGHTENER,042507
173
SCREW , Replaced By: N308676012031
173
SCREW LEFT AND RIGHT BEARING BRACKETS TO CAB
182
PULLEY FAN DRIVE 180 MM
182
PULLEY ONE-GROOVE,ELBOWED 188 MM
182
PULLEY180 MM,000475
185
HUB
185
HUB
188
SCREW VALVE TO BRACKET
191
NUT , Replaced By: N913004008001
191
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
194
GROOVED BALL BEARING
197
SPACER TUBE
200
LOCK RING52X2 MM
203
SEAL RING
206
SPACER WASHER BELT TIGHTENER 0.20 MM
206
SPACER WASHER BELT TIGHTENER 0.50 MM
209
LOCK RING
212
EXPANSION PLUG
212
EXPANSION PLUG
215
SEAL RING BATTERY MASTER SWITCH
218
NUT TIGHTENER PULLEY
221
SCREW PLUG 4/2-WAY VALVE
221
SCREW PLUG AIR DEHYDRATOR
224
SEAL RING PNEUMATIC VALVE
227
V-BELT FROM VIBRATION DAMPER TO TIGHTENER PULLEY 12.5X1950 MM,000164
227
V-BELT , Replaced By: A0039974892
227
V-BELT , Replaced By: A0079976592
227
V-BELT SET2 PIECES 12.5X1950 MM
227
V-BELT REFRIGERANT COMPRESSOR 12.5X1125 MM, 309.370-391 FROM CHASSIS 010600, 309.400-426 FROM CHASSIS 076956, 310.300-326 FROM CHASSIS 012889, 310.400-426 FROM CHASSIS 00 0001
230
V-BELT SET2 PIECES
999
RECEPTACLE SILICONE GREASE, FILLING QUANTITY: 70 CCM,TO 002 205 65 06
