Поз.
Артикул
Описание
173
HOSE HOSE TO AIR INTAKE PIPE & TO AIR COMPRESSOR & ENGINE BREATHER,RESP., ORDER BY THE METER
176
CLAMP HOSE TO AIR CLEANER AND TO AIR COMPRESSOR
176
CLAMP HOSE TO COOLING WATER PIPE
179
HOSE AT AIR COMPRESSOR, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
179
HOSE AT AIR COMPRESSOR, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY, Replaced By: A6285281882
179
INTAKE HOSE AT AIR COMPRESSOR, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY, Replaced By: A6285281782
179
HOSE TO RESONATOR, Replaced By: A6285283882
179
INTAKE HOSE TO RESONATOR, AS OF PRODUCTION BREAKPOINT DATE 09.99
179
HOSE TO RESONATOR
182
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
182
CLAMP HOSE TO INTAKE MANIFOLD 25-40X13MM,V 207570
185
AIR INTAKE PIPE FROM CONNECTING HOSE TO ENGINE
188
AIR INTAKE PIPE FROM CONNECTING HOSE TO ENGINE,095846
191
CLAMP MOUNTING PARTS, NOT USED
194
BRACKET AIR INTAKE PIPE TO ENGINE
197
SPACER TUBE FUEL DELIVERY LINE FIXTURE AT INTAKE MANIFOLD,CYLINDER NO.: 8,423.900-000-479498
200
CLAMP25-40X13 MM
200
CLAMP HOSE TO BRACKET 25/20,5 206397
200
CLAMP HOSE TO COOLING WATER PIPE
203
SCREW PIPE CLAMP
206
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
209
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL M8X16 MM
209
HEXALOBULAR BOLT. SCREW MANUAL PUMP BRACKET TO FENDER BRACKET
212
PIPE SOCKET (INTAKE PIPE-SOCKET)
212
COVER
215
SPRING WASHER LICENSE PLATE TO BRACKET
218
HEXAGON NUT ELECTRIC CABLE TO ALTERNATOR TERMINAL B-
218
NUT SPRING-LOADED PUSH ROD
218
NUT , Replaced By: N304032006004
218
NUT , Replaced By: N913023006001
221
HOSE ALTERNATOR BREATHING
221
HOSE ALTERNATOR AIR INTAKE 70X40MM
224
CLAMP HOSE TO RETARDER 60-80X13 MM
224
CLAMP , Replaced By: N000000000673
224
CLAMP HOSE TO RADIATOR,PIPE ELBOW,AND WATER PUMP 60-80X13 MM
227
PROTECTIVE GRILLE ALTERNATOR AIR INTAKE
227
PROTECTIVE GRILLE ALTERNATOR AIR INTAKE
230
LOOM TIE LINE MOUNTING
239
RESONATOR ,095847
