Поз.
Артикул
Описание
5
STEP COMPLETE TO A 628 660 30 28
7
EXPANSION PLUG LEFT TO A 628 890 35 29
7
COVERING LEFT TO A 628 660 30 28
7
COVERINGTO A 628 660 30 28, Replaced By: A6286660109
9
COVERINGTO A 628 660 30 28, Replaced By: A6286660109
9
EXPANSION PLUG RIGHT TO A 628 890 35 29
9
COVERING RIGHT TO A 628 660 30 28
11
SUPPORT ROLLERTO A 628 660 30 28
11
BEARING BRACKET LEFT,WITH STEP SENSOR DETECTION TO A 628 890 35 29
14
SPINDLETO A 628 660 30 28
14
DRIVE SHAFTTO A 628 890 35 29
17
BEARING BRACKETTO A 628 890 35 29
17
BEARING BRACKETTO A 628 660 30 28
20
SWITCH APPROXIMATION SWITCH TO A 628 660 30 28
20
SWITCH APPROXIMATION SWITCH TO A 628 890 35 29
23
BEARING BRACKET RIGHT,WITH STEP SENSOR DETECTION TO A 628 890 35 29
23
SUPPORT ROLLERTO A 628 660 30 28
26
SPRINGTO A 628 660 30 28
26
SPRINGTO A 628 890 35 29
29
FLAP COMPLETE TO A 628 890 35 29
29
FLAP COMPLETE TO A 628 660 30 28
32
HINGE
35
BRACKETTO A 628 890 35 29
35
ANGLETO A 628 660 30 28
38
RUBBER BUFFERTO A 628 890 35 29, Replaced By: A0019875240
38
SILENT BLOCKTO A 628 660 30 28
38
RUBBER BUFFER COVERING TO FRAME
41
MOUNTING FRONT TO A 628 660 30 28
41
MOUNTING FRONT TO A 628 890 35 29
44
MOUNTING CENTRAL TO A 628 660 30 28
44
MOUNTING CENTRAL TO A 628 890 35 29
47
ROD EMERGENCY CONTROL TO A 628 660 30 28
47
ROD EMERGENCY CONTROL TO A 628 890 35 29
50
MOUNTING REAR TO A 628 660 30 28
50
MOUNTING REAR TO A 628 890 35 29
53
JOINTTO A 628 890 35 29
56
CHAINTO A 628 890 35 29
56
CHAINTO A 628 660 30 28
59
BRACKETTO A 628 660 30 28
62
ELECTRIC MOTORTO A 628 890 35 29
62
ELECTRIC MOTORTO A 628 660 30 28
65
SWITCH APPROXIMATION SWITCH TO A 628 660 30 28
65
SWITCH
68
NUTTO A 628 660 30 28
71
GAS-OPERATED STRUTTO A 628 890 35 29
71
GAS SPRINGTO A 628 660 30 28
74
CARRIAGE COMPLETE TO A 628 660 30 28
77
ROLLERTO A 628 660 30 28
77
ROLLERTO A 628 890 35 29
80
BRACKETTO A 628 660 30 28
80
HINGETO A 628 660 35 28
83
STOPTO A 628 660 30 28
86
CRANKTO A 628 660 30 28
86
CRANKTO A 628 890 35 29
92
RETAINING COLLAR
92
NUT
95
PLUG 7-POLE
98
PLUG 7-POLE
101
PLUG BIPOLAR
104
PLUG BIPOLAR
200
ELECTRIC CABLE TIMING
203
ELECTRIC CABLE
206
CONTROL UNIT
