Поз.
Артикул
Описание
12
BRACKET TO TAILPIPE, Replaced By: A6284925242
12
BRACKET
13
BRACKET
14
BRACKET
16
BRACKET , UNTIL PRODUCTION BREAKPOINT DATE 28.02.09
16
BRACKET
17
BRACKET , UNTIL PRODUCTION BREAKPOINT DATE 28.02.09
17
BRACKET , UNTIL PRODUCTION BREAKPOINT DATE 28.02.09, Replaced By: A6284905340
24
DASHPOT
24
INSULATION
25
BUFFER
30
CLAMP EXHAUST SYSTEM D124,5MM, Replaced By: A6554920140
30
CLAMP , Replaced By: N071555124501
31
CLAMP
31
CLAMP FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
34
HEXAGON HEAD BOLT AUTOMATIC TRANSMISSION AT ENGINE M10X60
35
SCREW BRACKET TO SIDE MEMBER M10X35
35
HEXAGON HEAD BOLT. SCREW CABLE HARNESS TO BRACKET M8X40
35
SCREW SHIFT LEVER TO BRACKET M8X30
36
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
36
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBERM 12X1.5X30
38
SCREW BRACKET TO DISC WHEEL M 10X16,D 315832
39
SCREW STRUT TO CROSS MEMBER M 10X25
40
SCREW , Replaced By: N910143008002
41
SCREW SHIFT LEVER TO BRACKET M8X30
42
HEXAGON HEAD BOLTM6X16, AS OF PRODUCTION BREAKPOINT DATE 15.02.08
43
NUT , Replaced By: A0009903150
45
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
46
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
46
HEXAGON NUT. NUT , Replaced By: N913023008002
46
NUT HORN TO BRACKET M8
46
NUT ENGINE MOUNTING M8
47
NUT HORN TO BRACKET M8
48
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
51
CONNECTOR , AS OF PRODUCTION BREAKPOINT DATE 01.07.08
51
FLANGE , UNTIL PRODUCTION BREAKPOINT DATE 30.06.08
51
FLANGE , UNTIL PRODUCTION BREAKPOINT DATE 30.06.08
53
EXHAUST PIPE
54
PLATE , UNTIL PRODUCTION BREAKPOINT DATE 30.06.08
55
CATALYTIC CONVERTER , Replaced By: A0014907914
55
CATALYTIC CONVERTER , AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS)01.03.2010
55
CATALYST , UP TO PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 28.02.2010
67
HEAT SHIELD. PROTECTIVE PLATE
68
BRACKET , AS OF PRODUCTION BREAKPOINT DATE 01.03.09
68
BRACKET , UNTIL PRODUCTION BREAKPOINT DATE 28.02.09, Replaced By: A6284905640
68
BRACKET , UNTIL PRODUCTION BREAKPOINT DATE 28.02.09
70
BRACKET , AS OF PRODUCTION BREAKPOINT DATE 01.03.09
70
BRACKET , UNTIL PRODUCTION BREAKPOINT DATE 28.02.09
76
BASE PLATE
78
BASE PLATE
80
HOSE
82
HOSE HIGH PRESSURE HOSE
84
CONNECTION FITTING
86
CONNECTION FITTING
88
CLAMP LINE MOUNTING 8/15
88
CLAMP ,K 147121, Replaced By: N000000000319
88
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
90
HEXAGON HEAD BOLT. SCREW RELAY TO APPARATUS PLATE M 5X20
92
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
95
NUT RELAY TO BRACKET M5
98
NUT AIR RESERVOIR,CONNECTIONS: "14,21,35"
98
NUT FITTING TO BRACKET,230274
99
NUT POWER CYLINDER TO BRACKET
99
NUTM24X1.5
130
NUT , Replaced By: N913023010002
136
TAILPIPE , UNTIL PRODUCTION BREAKPOINT DATE 31.12.07
136
TAILPIPE , AS OF PRODUCTION BREAKPOINT DATE 01.01.08
233
WASHER PUMP TO CONSOLE
236
HEXAGON HEAD BOLT
239
SEALING STRIP , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
243
THREADED PLATE , AS OF PRODUCTION BREAKPOINT DATE 01.03.09
246
BRACKET , AS OF PRODUCTION BREAKPOINT DATE 01.03.09
249
BRACKET , AS OF PRODUCTION BREAKPOINT DATE 01.03.09
