Поз.
Артикул
Описание
5
DIFFERENTIAL CASE
5
DIFFERENTIAL GEAR
5
DIFFERENTIAL GEAR ,053410
5
DIFFERENTIAL CASE , TO REAR AXLES 345 350 00 00, 045 350 00 00,045 350 04 00, 345 350 87 00,345 350 88 00,345 350 89 00 345.000-008.024.101-121 UP TO IDENT NO. 588185,FROM IDENT NO. 588186 SEE MICROFICHE 816,MODEL 743.0, 345.021.033 UP TO IDENT NO 588185,FROM IDENT NO. 588186 SEE MICROFICHE 816,MODEL 745.0308298
8
SCREW ,2 125298
8
SCREW
11
SIDE GEAR
11
SIDE GEAR ,053410
14
THRUST WASHER2 MM
14
THRUST WASHER , Replaced By: A6743530362
14
THRUST WASHER
17
DIFFERENTIAL SPIDER
17
DIFFERENTIAL SPIDER , Replaced By: A3443537020
17
DIFFERENTIAL SPIDER
17
DIFFERENTIAL SPIDER
20
DIFFERENTIAL PINION
20
DIFFERENTIAL PINION ,053410
23
SPHERICAL WASHER
23
SPHERICAL WASHER
26
DIFFERENTIAL GEAR PARTS KIT,053410
29
LOCK
29
SCREW RING GEAR TO DIFFERENTIAL CASE
29
SCREW , Replaced By: A3839900801
29
SCREW , Replaced By: A3839900301
32
RING GEAR AND PINION RATIO: 48:7 GLEASON
32
RING GEAR AND PINION RATIO: 48:7 OERLIKON
32
RING GEAR AND PINION RATIO: 40:7 OERLIKON
35
TAPERED ROLLER BEARING
35
TAPERED ROLLER BEARING
35
TAPERED ROLLER BEARING
35
TAPERED ROLLER BEARING
35
TAPERED ROLLER BEARING
35
TAPERED ROLLER BEARING , TO REAR AXLES 345 350 00 00, 045 350 00 00,045 350 04 00, 345 350 87 00,345 350 88 00,345 350 89 00 345.000-008.024.101-121 UP TO IDENT NO. 588185,FROM IDENT NO. 588186 SEE MICROFICHE 816,MODEL 743.0, 345.021.033 UP TO IDENT NO 588185,FROM IDENT NO. 588186 SEE MICROFICHE 816,MODEL 745.0
35
TAPERED ROLLER BEARING
38
SCREW COLLAR DIFFERENTIAL GEAR
41
LOCK
44
SCREW RIGHT COVERING
47
TOOTHED WASHER
50
CYLINDR. ROLLER BEARING
50
CYLINDR. ROLLER BEARING
50
CYLINDR. ROLLER BEARING
50
CYLINDR. ROLLER BEARING
53
LOCK RING. RETAINING RING OIL PUMP TO TRANSMISSION CASE
56
SNAP RING
59
THRUST WASHER , Replaced By: A6703530752
59
THRUST WASHER , Replaced By: A6703533752
59
SPACER WASHER AS REQUIRED 0.10 MM
59
SPACER WASHER , Replaced By: A6703530652
59
SPACER WASHER , Replaced By: A6703530552
62
TAPERED ROLLER BEARING
62
TAPERED ROLLER BEARING
62
TAPERED ROLLER BEARING
62
TAPERED ROLLER BEARING
62
TAPERED ROLLER BEARING
65
SPACER RING
68
SPACER WASHER AS REQUIRED, STEEL 10.28 MM
68
SPACER WASHER AS REQUIRED 10.30 MM
68
SPACER WASHER AS REQUIRED, STEEL 10.32 MM
68
SPACER WASHER AS REQUIRED 10.34 MM
68
SPACER WASHER AS REQUIRED 10.36 MM
68
SPACER WASHER AS REQUIRED, STEEL 10.38 MM
68
SPACER WASHER AS REQUIRED 10.40 MM
68
SPACER WASHER AS REQUIRED 10.42 MM
68
SPACER WASHER AS REQUIRED, STEEL 10.44 MM
68
SPACER WASHER AS REQUIRED 10.46 MM
68
SPACER WASHER AS REQUIRED 10.48 MM
68
SPACER WASHER AS REQUIRED 10.50 MM
68
SPACER WASHER AS REQUIRED 10.10 MM
68
SPACER WASHER AS REQUIRED 10.12 MM
68
SPACER WASHER AS REQUIRED 10.14 MM
68
SPACER WASHER AS REQUIRED 10.16 MM
68
SPACER WASHER AS REQUIRED, STEEL 10.18 MM
68
SPACER WASHER AS REQUIRED 10.20 MM
68
SPACER WASHER AS REQUIRED, STEEL 10.22 MM
68
SPACER WASHER AS REQUIRED 10.24 MM
68
SPACER WASHER AS REQUIRED, STEEL 10.26 MM
68
SPACER RING AS REQUIRED 10.52 MM
68
SPACER WASHER AS REQUIRED, BRASS 10.10 MM
68
SPACER WASHER AS REQUIRED, BRASS 10.12 MM
68
SPACER WASHER AS REQUIRED 10.14 MM
68
SPACER WASHER AS REQUIRED, BRASS 10.16 MM
68
SPACER WASHER AS REQUIRED, BRASS 10.18 MM
68
SPACER WASHER AS REQUIRED 10.20 MM
68
SPACER WASHER AS REQUIRED 10.22 MM
68
SPACER WASHER AS REQUIRED 10.24 MM
68
SPACER WASHER AS REQUIRED, BRASS 10.26 MM
68
SPACER WASHER AS REQUIRED, BRASS 10.28 MM
68
SPACER WASHER AS REQUIRED 10.30 MM
68
SPACER WASHER AS REQUIRED 10.32 MM
68
SPACER WASHER AS REQUIRED 10.34 MM
68
SPACER WASHER AS REQUIRED 10.36 MM
68
SPACER WASHER AS REQUIRED 10.38 MM
68
SPACER WASHER AS REQUIRED, BRASS 10.40 MM
68
SPACER WASHER AS REQUIRED 10.42 MM
68
SPACER WASHER AS REQUIRED 10.44 MM
68
SPACER WASHER AS REQUIRED, BRASS 10.46 MM
68
SPACER WASHER AS REQUIRED 10.48 MM
68
SPACER WASHER AS REQUIRED, BRASS 10.50 MM
68
SPACER RING AS REQUIRED, BRASS 10.52 MM
71
THRUST WASHER
74
SCREW COLLAR
77
LOCK SCREW COLLAR
80
SCREW
83
TOOTHED WASHER
86
SEAL RING , Replaced By: A0169976847
86
SEAL RING , Replaced By: A0089970747
86
SEAL RING
89
FLANGE
92
PROTECTIVE PLATE
95
NUT FOLLOWER FLANGE TO PROPELLER SHAFT TO 384 410 70 30
95
NUT COUPLING FLANGE TO DRIVE SHAFT,5 298189
