OM 904 LA - 900.912 - 20 ENGINE COOLING SYSTEM
Поз.
Артикул
Описание
495
PIPE LINE DELIVERY LINE
510
PIPE LINE DELIVERY LINE
515
VALVE
520
CAP
522
SEAL RING HOSE TO EXPANSION VALVE 7.5 MM
525
SEAL RING FROM LIQUID TANK TO T-FITTING
530
SEAL RING HOSE TO CONDENSER 14 MM
530
O-RING HOSE TO EXPANSION VALVE 17X2
535
PIPE LINE SUCTION LINE
540
VALVE , NOT USED
545
CAP , NOT USED
550
SEAL RING HOSE TO CONDENSER 14 MM
555
TANK LIQUID TANK
555
TANK LIQUID TANK
555
TANK LIQUID TANK
555
TANK LIQUID TANK
560
SWITCH ,K 157608
560
SWITCH (PRESSURE SWITCH)
560
SWITCH (PRESSURE SWITCH)
565
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
