Mercedes A0015458728 - РАЗЪЕМ

208CDI 901.611 FROM IDENT-NR. R337627, 5337627, A901274

54 ELECTRICAL EQUIPMENT AND INSTRUMENTS - 095 RELAY,FUSEBOX AND CONTROL MODULES IN SEAT FRAME IL. 4

Поз.
Артикул
Описание
5
A0028203556
EXTERIOR LAMP (CONTOUR LAMP),FRONT TOP,LEFT
5
A0028203656
EXTERIOR LAMP RIGHT
8
A0015458728
PIN BUSHING HOUSING BIPOLAR
11
A0075458226
SOCKET. PIN BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 2,5 MM2
14
N072601012701
BULB5 W, Replaced By: N072601012703
14
N072601012703
BULB5 W
17
N000000000820
TAPPING SCREW TELEPHNE CONSOLE ON CENTER CONSOLE
18
A6908227002
PAD LEFT
18
A6908227102
PAD RIGHT
20
A0028206456
EXTERIOR LAMP (SIDE MARKER LAMP),AMBER, P 605731 R 000001
20
A0038202256
END-OUTLINE MARKER LAMP
23
N000000000853
BULBTO A 6955407048/7148,3825400311/0411
26
A0115450326
PIN BUSHING HOUSING BIPOLAR
29
A0055456826
CONTACT SPRINGTO 657 540 50 10
29
A0115457626
CONTACT SPRING WITH GASKET 1.5-2.5 MM2
30
A0005452839
WIRE SEAL
30
A0005452939
CORE BUNDLE SEALING. WIRE SEAL WITHE 1.0-2.5 MM2, PIN 57 - 62
32
A0039944345
LOCK , P 605731 R 000001
35
N000000000455
TAPPING SCREW. SHEET METAL SCREW REAR BUMPER
