Поз.
Артикул
Описание
10
RADIATOR , A 02405520090703 A 02654120100930801
12
DETENT SPRING COOLANT HOSE, LEFT, TO RADIATOR SCB3646.4MM
14
DETENT SPRING FILLING HOSE TO RADIATOR SCB1727MM
15
SLEEVE TRANSMISSION OIL LINE AT RADIATOR
30
AIR BAFFLE UPPER AIR DUCTING, A 26557620081001809
40
AIR DUCT LOWER AIR DUCTING
40
AIR DUCT LOWER AIR DUCTING, A 30200020090930800 L 00000120120601
40
AIR BAFFLE LOWER AIR DUCTING
50
CAPACITOR AIR CONDITIONER, A 26557620081001809, Replaced By: A2215001354
50
CAPACITOR AIR CONDITIONER, A 26557620081001809
60
REFRIGERANT CONDENSER AIR CONDITIONER, A 26557620081001809
70
MOUNTING FRAME AIR CONDITIONER CONDENSER, A 26557620081001809
70
MOUNTING FRAME AIR CONDITIONER CONDENSER
75
HEXALOBULAR BOLT BRACKET TO BRACKET M8X16
150
CUP SEAL BOTTOM
200
RUBBER MOUNT RADIATOR BOTTOM, A 02588420100630
210
BEARING TOP LEFT AND RIGHT, J 06236120041209
220
CLIP RADIATOR TOP
250
BLOWER
250
BLOWER
280
CLIP-TYPE NUT FAN SHROUD TO RADIATOR
290
CLAMP20 MM
300
WIRING HARNESS AT BLOWER, F 92165420120501
310
CLAMP LINE MOUNTING 15-18 MM,V 207570
320
SCREW W COLLAR A DRIVEM5X35
330
RIVET ON CAB FLOOR UNDER STEP
330
RIVET
