Поз.
Артикул
Описание
8
VALVE CENTRAL AXLE BRAKE CIRCUIT
16
REPAIR KIT PRESSURE RELIEF VALVE
24
VALVE OVERFLOW VALVE WITH RETURN FLOW KNORR
32
SEAL RINGWABCO
40
DIAPHRAGMWABCO
48
REPAIR KIT
56
FITTING LOAD/NO-LOAD VALVE,CONNECTIONS: "10,21"
64
SCREW PLUG SECONDARY CONSUMING UNIT AIR RESERVOIR
72
NUT CHECK VALVE TO AIR RESERVOIR
80
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
88
O-RING CHECK VALVE TO AIR RESERVOIR
96
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
104
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
112
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
120
SWITCH EXHAUST BRAKE
999
VALVE PRESSURE LIMIT
