Поз.
Артикул
Описание
1
ENGINE STAY (ENGINE MOUNTING)
2
HEXAGON HEAD BOLT , Replaced By: A0029902704
2
SCREW , Replaced By: N308676012013
3
BEARING BRACKET
3
BEARING BRACKET
3
BEARING BRACKET
3
BEARING BRACKET
5
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
5
SCREW , Replaced By: N308676012026
15
ENGINE CROSS MEMBER
20
BRACKET
20
BRACKET
50
FRONT SPRING BRACKET
50
FRONT SPRING BRACKET
60
WASHER VALVE TO BRACKET
60
WASHER , Replaced By: N001440027000
62
SCREW BRACKET TO SIDE MEMBER
62
SCREW , Replaced By: N304017010002
80
BEARING BRACKET (HAND BRAKE LEVER)
120
SCREW SPRING CLAMP TO SPRING LEAF NO.2
121
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
121
SCREW , Replaced By: N304017008027
123
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
124
NUT
999
FRAME , ONLY APPLICABLE TO 360.050
999
FRAME , ONLY APPLICABLE TO 360.051,071
999
FRAME , ONLY APPLICABLE TO 360.052,072
999
FRAME , ONLY APPLICABLE TO 360.053,073
999
FRAME , ONLY APPLICABLE TO 360.054
999
FRAME , ONLY APPLICABLE TO 360.062
999
FRAME , ONLY APPLICABLE TO 360.063
999
FRAME , ONLY APPLICABLE TO 360.055
999
FRAME , ONLY APPLICABLE TO 360.056,091
999
FRAME , ONLY APPLICABLE TO 360.057,092
999
FRAME , ONLY APPLICABLE TO 360.058,093
999
FRAME , ONLY APPLICABLE TO 360.059
999
FRAME , ONLY APPLICABLE TO 360.082
999
FRAME , ONLY APPLICABLE TO 360.083
999
SHIM BEARING BRACKET TO FRAME
999
WASHER LEFT AND RIGHT CONSOLES TO CAB
999
SCREW , Replaced By: N304017008034
999
SCREW EXHAUST PIPE TO BRACKET
999
SCREW HAND PUMP TO BRACKET
999
NUT STRAP TO SUPPORT
999
SCREW BRACKET TO FRAME M 12X35
999
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X40
999
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
999
SCREW BRACKET TO CAB CONSOLE,K 035197
999
SCREW BRACKET TO CROSS CONNECTION STRUT
999
RIVET REINFORCEMENT TO SIDE MEMBER
999
RIVET REAR CROSS MEMBER 10X38 MM
999
RIVET BEARING BRACKET TO SIDE MEMBER, TO BE ADAPTED DURING ASSEMBLY
999
RIVET REAR CROSS MEMBER 12X42 MM
999
LOCK WASHER FITTING TO BRACKET
999
RIVET
999
RIVET , Replaced By: N910005012002
999
RIVET , Replaced By: N910005012080
999
RIVET , Replaced By: N910005010003
999
RIVET , Replaced By: N910005010006
999
CONSOLE , Replaced By: A3522400010
999
BEARING BRACKET CLUTCH OPERATION, 908306
999
BRACKET AT CROSS MEMBER NO. 2
999
ENGINE STAY , Replaced By: A3602400110
999
ENGINE CROSS MEMBER REAR
999
FRAME , ONLY APPLICABLE TO 360.014
999
FRAME , ONLY APPLICABLE TO 360.015
999
FRAME , ONLY APPLICABLE TO 360.034
999
FRAME , ONLY APPLICABLE TO 360.064
999
FRAME , ONLY APPLICABLE TO 360.065
999
FRAME , ONLY APPLICABLE TO 360.084
999
FRAME , ONLY APPLICABLE TO 360.085
999
FRAME , ONLY APPLICABLE TO 360.001
999
FRAME , ONLY APPLICABLE TO 360.001
999
FRAME , ONLY APPLICABLE TO 360.011
999
FRAME , ONLY APPLICABLE TO 360.021
999
FRAME , ONLY APPLICABLE TO 360.002,012
999
FRAME , ONLY APPLICABLE TO 360.013
999
FRAME , ONLY APPLICABLE TO 360.022
999
FRAME , ONLY APPLICABLE TO 360.003
999
FRAME , ONLY APPLICABLE TO 360.023
999
FRAME , ONLY APPLICABLE TO 360.004
999
FRAME , ONLY APPLICABLE TO 360.006
999
FRAME , ONLY APPLICABLE TO 360.007,032
999
FRAME , ONLY APPLICABLE TO 360.033
999
FRAME , ONLY APPLICABLE TO 360.008
