Поз.
Артикул
Описание
100
FOLLOWER BELL HUB
100
FOLLOWER , Replaced By: A3543530036
105
SHIFTING FORK DIFFERENTIAL LOCK
110
BEARING BUSHING SHIFTING FORK TO REAR AXLE HOUSING
115
SEAL RING SHIFTING FORK TO REAR AXLE HOUSING
120
PAD , Replaced By: A3273510119, +002A3273510019
120
PAD SHIFTING FORK TO REAR AXLE HOUSING 0.50 MM
120
PAD SHIFTING FORK TO REAR AXLE HOUSING 0.10 MM
125
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
127
SCREW BRACKET TO SIDE MEMBER
130
BEARING BUSHING SHIFTING FORK TO REAR AXLE HOUSING
135
LEVER DIFFERENTIAL LOCK
140
PROTECTIVE CAP SHIFTING FORK TO REAR AXLE HOUSING
195
DIFFERENTIAL GEAR LESS RING GEAR AND PINION
205
SCREW COVER TO DIFFERENTIAL CASE M 14X100, FROM REAR AXLE 036776
205
SCREW DIFFERENTIAL GEAR 66 MM
210
SCREW COVER TO DIFFERENTIAL CASE M 14X125, FROM REAR AXLE 036776
210
SCREW COVER TO DIFFERENTIAL CASE M 12X92, UP TO REAR AXLE 036775
210
SCREW DIFFERENTIAL SPIDER,PIVOT: 29 MM
215
DIFFERENTIAL SPIDER DIFFERENTIAL GEAR 29 MM
215
DIFFERENTIAL SPIDER , Replaced By: A3603530020
215
DIFFERENTIAL SPIDER DIFFERENTIAL GEAR 30 MM
215
DIFFERENTIAL SPIDER DIFFERENTIAL SPIDER,PIVOT: 29 MM
220
DIFFERENTIAL PINION DIFFERENTIAL SPIDER,PIVOT: 30 MM
220
DIFFERENTIAL PINION , Replaced By: A3543530014
220
DIFFERENTIAL PINION DIFFERENTIAL SPIDER,PIVOT: 29 MM
225
THRUST WASHER , Replaced By: A3273534662
225
THRUST WASHER DIFFERENTIAL PINION 1.00X29 MM, ONLY INSTALL PARTS MADE OF THE SAME MATERIAL
225
THRUST WASHER DIFFERENTIAL PINION 1.00X29 MM
225
THRUST WASHER DIFFERENTIAL PINION 1.50X30 MM, ONLY INSTALL PARTS MADE OF THE SAME MATERIAL
225
THRUST WASHER DIFFERENTIAL PINION 1.50X30 MM, ONLY INSTALL PARTS MADE OF THE SAME MATERIAL
230
SIDE GEAR , Replaced By: A3543530015
230
SIDE GEAR DIFFERENTIAL SPIDER,PIVOT: 29 MM
230
SIDE GEAR DIFFERENTIAL SPIDER,PIVOT: 30 MM
232
REPAIR KIT DIFFERENTIAL SPIDER,PIVOT: 29 MM
232
REPAIR KIT DIFFERENTIAL SPIDER,PIVOT: 30 MM
235
THRUST WASHER1.50 MM, ONLY INSTALL PARTS MADE OF THE SAME MATERIAL
235
THRUST WASHER AS REQUIRED 1.70 MM, ONLY INSTALL PARTS MADE OF THE SAME MATERIAL
235
THRUST WASHER , Replaced By: A3273533662
235
THRUST WASHER , Replaced By: A3273533462
235
THRUST WASHER , Replaced By: A3273533762
235
THRUST WASHER1.60 MM, ONLY INSTALL PARTS MADE OF THE SAME MATERIAL
235
THRUST WASHER DIFFERENTIAL GEAR 1.80 MM, ONLY INSTALL PARTS MADE OF THE SAME MATERIAL
235
THRUST WASHER , Replaced By: A3273533262
240
RING GEAR AND PINION8:39
240
RING GEAR AND PINION
240
RING GEAR AND PINION RATIO: 39:8
240
RING GEAR AND PINION , Replaced By: A3023501739
240
RING GEAR AND PINION RATIO: 7:43
240
RING GEAR AND PINION , Replaced By: A3613501239
240
RING GEAR AND PINION RATIO: 48:7
245
SCREW RING GEAR AND PINION TO DIFFERENTIAL CASE,3129051
245
SCREW RING GEAR AND PINION TO DIFFERENTIAL CASE,3129050
250
TAPERED ROLLER BEARING INSIDE
250
TAPERED ROLLER BEARING INSIDE
250
TAPERED ROLLER BEARING INSIDE
250
TAPERED ROLLER BEARING INSIDE
330
CYLINDER ONE-CHAMBER WABCO
330
CYLINDER ONE-CHAMBER BOSCH
335
BUSHINGBOSCH
337
BOOTBOSCH
339
BUSHINGBOSCH
341
SEAL RING COMPRESSED AIR CYLINDER TO BRACKET BOSCH
343
BOOTBOSCH
345
NUT
351
REPAIR KIT ONE-CHAMBER COMPRESSED AIR CYLINDER WABCO
355
YOKE COMPRESSED AIR CYLINDER TO BRACKET
360
PIN CYLINDER TO SHIFTING FORK
365
LOCK PLATE CYLINDER TO SHIFTING FORK
370
WASHER COMPRESSED AIR CYLINDER TO BRACKET
375
LOCK PLATE CYLINDER TO SHIFTING FORK
380
BRACKET LEVER TO SHIFTING FORK
382
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
384
SCREW CLAMP TO BRACKET AND TO PIPE
999
SCREW , Replaced By: A3859901101
999
SIDE GEAR ,P 273088
999
LEVER RIGHT,2 068749
999
LEVER LEFT,2 068749
999
REAR AXLE
999
REAR AXLE RATIO: 7:48
999
SCREW , Replaced By: N000960018062
999
SPACER RING
999
SLIDE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3853530149, +001A3833530276
999
PLUG
999
OIL COLLECTOR
999
BELLOWS COMPRESSED AIR CYLINDER
