Поз.
Артикул
Описание
15
CRANKCASE ,731785910950, Replaced By: A3530102808, +001A3660150504, +001A3520150160, +001A3622010080, +001A3622010180, +004N914126008029
30
SCREW PLUG
33
SEAL RING TO MOUNT FUEL LINES 16X22 - TO A 688 470 00 90
35
SLEEVE
38
SLEEVE , UP TO ENGINE 289000 YEAR OF MANUFACTURE 1993
41
CYLINDRICAL PIN
44
INTERMEDIATE PIECE (ADAPTER), 314 342575 352 547156
45
SEAL RING LINE TO OIL PUMP
49
CYLINDRICAL PIN CYLINDER HEAD TO CYLINDER CRANKCASE
54
SCREW PLUG OIL PASSAGE
56
BEARING CAP , Replaced By: A3520100823
56
BEARING CAP , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE, Replaced By: A3660100223
56
BEARING CAPNO.1,3,4
58
DOWEL PIN CRANKSHAFT BEARING CAP TO 366 010 03 23, 02 23, 03 23
58
CYLINDRICAL PIN
60
BEARING CAP , Replaced By: A3520100923
60
BEARING CAP , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 104742, Replaced By: A3660100023
60
BEARING CAP , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE, Replaced By: A3660100123
60
BEARING CAPNO.2
61
DOWEL PIN CRANKSHAFT BEARING CAP TO 366 010 03 23, 02 23, 03 23
61
CYLINDRICAL PIN
63
BEARING CAPNO.5,A 003512
63
BEARING CAP , Replaced By: A3520101023
63
BEARING CAP , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE, Replaced By: A3660100323
65
DOWEL PIN CRANKSHAFT BEARING CAP TO 366 010 03 23, 02 23, 03 23
65
CYLINDRICAL PIN
66
SAFETY PIN. PIN ,A 003512
67
SEAL RING CRANKSHAFT SEALING,REAR,A 003512
67
SEAL RING , Replaced By: A0019973141
67
SEAL RING , Replaced By: A0019974141
68
SCREW
68
SCREW CRANKSHAFT BEARING CAP TO CYLINDER CRANKCASE, WHEN INSTALLING MODIFIED CRANKSHAFT BEARING BOLT REPLACE ALL CRANKSHAFT BEARING BOLTS WITH THIS VERSION
70
EXPANSION PLUG
90
SCREW PLUG WATER DRAIN
91
SEAL RING VALVE TO VALVE,K 025179
93
CYLINDER LINER , Replaced By: A3620110310
93
CYLINDER LINER , Replaced By: A3620110310
93
CYLINDER LINER , Replaced By: A3620110310
119
REPAIR KIT , Replaced By: A3440500051
119
REPAIR KIT , Replaced By: A3440500051
119
CAMSHAFT BEARING PARTS KIT
122
TIMING CASE , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 046891, Replaced By: A3660100133
122
TIMING CASE ,070205
125
CYLINDRICAL PIN , UP TO CHASSIS 447270 FROM CHASSIS SEE SPARE PARTS LIST 817,INAPPLICABLE TO R.H.D.AND SUPERCHARGED ENGINE VEHICLES
127
CYLINDRICAL PIN
128
SCREW BRACKET TO INTAKE MANIFOLD
130
LOCK WASHER RAIL TO BATTERY SUPPORT
131
SCREW PROPELLER SHAFT TO COUPLING FLANGE
132
THREADED INSERT REPAIR SIZE
132
THREADED INSERT
132
THREADED INSERT
134
GASKET TIMING CASE TO CYLINDER CRANKCASE
134
GASKET , Replaced By: A3660150180
134
GASKET TIMING CASE TO CYLINDER CRANKCASE
135
SCREW , Replaced By: N304017010040
137
COVER , Replaced By: A3660150401
139
GASKET TIMING CASE COVER TO TIMING CASE,070205
139
GASKET , Replaced By: A3660150020
141
SEAL RING , Replaced By: A0129979647
141
SEAL RING , Replaced By: A0129979647
141
SEAL RING , Replaced By: A0149971647
141
SEAL RING
141
SEAL RING , ONLY FOR USE WITH SHEET METAL VERSION TIMING CASE 352 015 00 01, Replaced By: A0149971647
141
SEAL RING
142
SPACER RING
143
SCREW TIMING CASE COVER & TIMING CASE TO CRANKCASE,070205
145
SCREW TIMING CASE COVER TO TIMING CASE
148
POINTER AT TIMING CASE COVER
150
SCREW TIMING CASE COVER & TIMING CASE TO CRANKCASE,070205
155
COVER
157
GASKET TIMING CASE LOCK
157
GASKET COVER TO TIMING CASE
160
SCREW , Replaced By: N304017006018
163
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
165
COVER
165
COVER LATERAL
165
COVER , Replaced By: A3660100216
165
COVER PUSH ROD CHAMBER COVER, UP TO ENGINE 234537 YEAR OF MANUFACTURE 1992
167
GASKET PUSH ROD CHAMBER COVER
169
SCREW COLD START SYSTEM TO BRACKET
171
SEAL RING PUSH ROD CHAMBER COVER TO CYLINDER CRANKCASE
222
BREATHER PIPE
225
SEAL RING
228
COVER OIL FILLER NECK
228
CAP OIL REFILLING
228
CAP , Replaced By: A3440180168
230
GASKET , Replaced By: A1020180080
230
GASKET COVER TO FITTING
231
EXPANSION PLUG OIL FILLER NECK
231
EXPANSION PLUG , Replaced By: A3660100019
232
SEAL RING
235
SCREW PLUG
999
SEAL RING , Replaced By: A0019973141
999
SEAL RING , Replaced By: A0019974141
999
SEAL RING , Replaced By: A0149971647
999
GASKET , Replaced By: A3660150180
999
GASKET COVER TO OIL COOLER
999
GASKET COVER TO OIL COOLER
999
GASKET , Replaced By: A3641840280
999
GASKET , Replaced By: A3661840080
999
BOOT , Replaced By: A3660530058
999
GASKET KIT , Replaced By: A3440101506
999
SHORT-BLOCK
999
ENGINE WITH BELL HOUSING
999
GASKET KIT
999
CRANKCASE CYLINDER CRANKCASE,832081
999
CYLINDER HEAD COVER
999
CYLINDER HEAD COVER
999
GASKET CYLINDER HEAD
999
GASKET CYLINDER HEAD
999
GASKET INTAKE AND EXHAUST MANIFOLDS TO CYLINDER HEAD
999
GASKET KIT OIL COOLER TO CYLINDER CRANKCASE TO 344 010 04 80
999
REPAIR KIT
999
GASKET KIT , Replaced By: A3520101980
999
GASKET KIT. GASKET , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 996747YEAR OF MANUFACTURE 1990, Replaced By: A3660100680
999
GASKET
999
GASKET
999
GASKET
999
SEAL RING , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 285673YEAR OF MANUFACTURE 1993, Replaced By: A3660150060
999
GASKET TIMING CASE COVER TO TIMING CASE
999
GASKET , Replaced By: A3660150020
999
BOOT INTAKE TO 352 05312 29-15 29
999
BOOT , Replaced By: A3660530158
999
GASKET INJECTION PUMP TO TIMING CASE
999
GASKET , Replaced By: A3661310280
999
GASKET , Replaced By: A3661310180
999
GASKET , Replaced By: A3522011680
999
GASKET , Replaced By: A3522011980
999
GASKET WATER PUMP COVER
999
GASKET WATER PUMP TO CYLINDER CRANKCASE
999
GASKET
999
GASKET , Replaced By: A3522032480
999
GASKET HEATING PIPE TO ENGINE
999
GASKET , Replaced By: A3662030380
999
GASKET , Replaced By: A3522032680
999
BOOT INTAKE AND EXHAUST,103938
999
GASKET KIT CYLINDER CRANKCASE,832082
999
GASKET OIL COOLER TO CYLINDER CRANKCASE,730881
999
GASKET , Replaced By: A3662010180
999
GASKET , Replaced By: A3522011780
999
GASKET OIL FILTER TO CYLINDER CRANKCASE, FROM ENGINE 923827-999999 YEAR OF MANUFACTURE 1988-1990 FROM ENGINE 100001 YEAR OF MANUFACTURE 1990
999
GASKET KIT OIL PAN
999
GASKET KIT OIL PAN
999
SEAL RING PUSH ROD CHAMBER COVER TO CYLINDER CRANKCASE
999
CYLINDER HEAD GASKET , Replaced By: A3660160220
999
CYLINDER HEAD GASKET , Replaced By: A3660160620
999
CYLINDER HEAD GASKET CYLINDER HEAD TO CYLINDER CRANKCASE
999
BOOT INTAKE
999
BOOT EXHAUST
999
GASKET AS REQUIRED 0.90 MM
999
GASKET AS REQUIRED 0.65 MM
999
GASKET , Replaced By: A3661840180
999
GASKET OIL FILTER TO CYLINDER CRANKCASE
999
GASKET OIL COOLER TO CYLINDER CRANKCASE
999
GASKET WATER PUMP TO CYLINDER CRANKCASE
999
GASKET PIPE SOCKET TO CYLINDER HEAD, UP TO IDENT NO.5 448662, FROM IDENT NO. 5 448663 SEE UNIT MICROFICHE
999
SEAL RING OIL COOLER TO COVER
999
SEAL RING PNEUMATIC VALVE
