Поз.
Артикул
Описание
2
WHEEL BRAKE CYLINDER44.45 MM,TEVES
3
SPRING , FOR 002 420 77 18,003 420 78 18
4
PROTECTIVE CAP , Replaced By: A3454237087
5
THRUST PINTEVES
6
VALVE , Replaced By: A3075530107
6
VALVE CLUTCH SLAVE CYLINDER
7
PROTECTIVE CAP , Replaced By: A0004217187
7
PROTECTIVE CAP ,5 962906
7
PROTECTIVE CAP , Replaced By: A0004217187
8
REPAIR KITTEVES
9
PROTECTIVE PLATE , FOR 002 420 77 18,003 420 78 18
10
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
11
SCREW BRACKET TO SIDE MEMBER
12
BRAKE ANCHOR PLATE , UP TO CHASSIS 910369EXCEPT FOR 501415-599999,FROM CHASSIS 910370,ALSO INSTALLED ON 501415-599999,SEE SPARE PARTS LIST 731. 3 OR 731.4
13
INSPECTION HOLE COVER
14
RIVET
15
ADJUSTING PIN , Replaced By: A3025860042
16
SPRING ADJUSTING ECCENTRIC TO BRAKE ANCHOR PLATE, 344.030,032,033,040,041,057,058 UP TO IDENT NO. 415524, FROM IDENT NO. SEE SPARE PARTS LIST 732.7
17
WASHER , UP TO CHASSIS 910369 ALSO INSTALLED ON 500001-501455,FROM CHASSIS 910370 AND 501456-599999 SEE SPARE PARTS LIST 103
18
NUT , Replaced By: A3589900051
18
NUT , UP TO CHASSIS 910369 ALSO INSTALLED ON 500001-501414,FROM CHASSIS 910370 AND 501415-599999 SEE SPARE PARTS LIST 744.3
19
OIL COLLECTOR , Replaced By: A3553340082
19
OIL COLLECTOR , 10/20 FROM IDENT NO. 796991,50/60 FROM IDENT NO. 790759 ALSO INSTALLED ON 500001-599999
23
BRAKE LINING (PARTS KIT) 15.3 MM, UP TO CHASSIS 910369 ALSO INSTALLED ON 500001-501414,FROM CHASSIS 910370 AND 501415-599999 SEE SPARE PARTS LIST 744.3
23
BRAKE LINING (PARTS KIT) (ASBESTOS-FREE BRAKE LINING) 15.30 MM,8X 341 423 42 10), UP TO CHASSIS 910369 ALSO INSTALLED ON 500001-501414,FROM CHASSIS 910370 AND 501415-599999 SEE SPARE PARTS LIST 744.3
23
BRAKE LINING (PARTS KIT) (BRAKE LINING 16.30 MM)
23
BRAKE LINING (PARTS KIT),REPAIR SIZE I (ASBESTOS-FREE BRAKE LINING) 16.30 MM
23
BRAKE LINING (PARTS KIT) (BRAKE LINING 17.30 MM)
23
BRAKE LINING (PARTS KIT),REPAIR SIZE II (ASBESTOS-FREE BRAKE LINING) 17.30 MM
24
RIVET BRAKE LINING 15 MM
27
REPAIR KIT , Replaced By: A3384200289
27
REPAIR KIT BRAKE SHOE SHACKLE, UP TO CHASSIS 910369 ALSO INSTALLED ON 500001-501455,FROM CHASSIS 910370 AND 501456-599999 SEE SPARE PARTS LIST 103
28
PIN SHACKLE TO BRAKE SHOE
29
LOCK RING TRANSMISSION CASE,TOP
30
PIN
31
SPACER WASHER
32
SPRING
33
LOCK , 344.030,032,033,040,041,057,058 UP TO IDENT NO. 415524, FROM IDENT NO. SEE SPARE PARTS LIST 732.7
34
PIVOT PIN SHACKLE TO BRAKE SHOE
35
LOCK RING TRANSMISSION CASE,TOP
36
SPRING SHORT
37
SPRING , UP TO CHASSIS 910369EXCEPT FOR 501415-599999,FROM CHASSIS 910370,ALSO INSTALLED ON 501415-599999,SEE SPARE PARTS LIST 731. 3 OR 731.4
38
PIN
39
FILLER
40
SPRING
40
SPRING , UP TO CHASSIS 910369 ALSO INSTALLED ON 500001-501455,FROM CHASSIS 910370 AND 501456-599999 SEE SPARE PARTS LIST 103
41
FILLER
42
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
43
NUT
999
FITTING AT DISTRIBUTOR,4 481289
999
FITTING , Replaced By: A0029906071
999
SEAL RINGTO 000 431 24 14
999
FITTING , Replaced By: A0029906171
999
SEAL RING , Replaced By: A0179974148
999
SEAL RINGTO 000 431 77 14,KNORR
999
WHEEL BRAKE CYLINDER LESS THRUST PIN 46.83 MM,TEVES
999
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
999
SEAL RINGTO 000 431 21 14,BOSCH, WITH BOSCH CHARACTERISTIC NUMBER 723
999
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
999
HOSE , Replaced By: A0009872827
999
SEAL RINGTO 000 429 16 31,4 940458
999
SEAL RING
999
SEAL RING101
999
REPAIR KIT BRAKE CAMSHAFT BEARING, FROM CHASSIS 674068 ALSO INSTALLED ON, 500001-599999,673550,673631,673890,673916-673918,673922,673927 UP TO CHASSIS 910369 ALSO INSTALLED ON 500001-501414,FROM CHASSIS 910370 AND 501415-599999 SEE SPARE PARTS LIST 744.3
999
THRUST SHACKLE , UP TO REAR AXLE029311, Replaced By: A3024201419, +001A3024230874, +001A3024940109, +001N000933008106, +001N912004008102
999
ADJUSTER. REPAIR KIT READJUSTMENT OF REAR WHEEL BRAKE,1 239645
999
REPAIR KIT BRAKE READJUSTMENT
999
SHACKLE
999
SLIDE , Replaced By: A3024210329
999
SLIDE BRAKE READJUSTMENT
999
ADJUSTING PIN , Replaced By: A3024230619, +004A3024210329, +004A3124211073
999
ADJUSTING LEVER RIGHT
999
PIN FROM BRAKE SHAFT TO BRAKE LEVER
999
REPAIR KIT , Replaced By: A3024202938
999
REPAIR KIT , Replaced By: A3024200067
999
REPAIR KIT , Replaced By: A3024203138
999
BRACKET , Replaced By: A3124761535
999
BRACKET HEATING WATER LINE
999
REPAIR KIT
999
REPAIR KIT , Replaced By: A3144200092
999
RUBBER STRIP , Replaced By: A3604750020
999
PAWL , 656999
999
CABLE PULLEY , UP TO IDENT NO. 674067 EXCEPT FOR 500001-599999, 673432, 673497, 673628,673629,673921
999
PAWL , 656999
999
CONSOLE , Replaced By: A3224320215, +002N913004012000
999
STRAP AIR RESERVOIR TO CONSOLE
999
CONSOLE AIR RESERVOIR TO SUPPORT
999
SEAL HOLDER
999
WASHER TRAILER COUPLING TO REAR CROSS MEMBER
999
BRAKE SHOE , Replaced By: A3384200219
999
REPAIR KIT BRAKE SHOE SHACKLE SPACER PIN
999
BRAKE SHOE LESS LINING
999
REPAIR KIT , Replaced By: A3384200082
999
LINE FROM TEST CONNECTION TO VALVE 400 MM,4 478330
999
LINE FROM CONNECTOR TO BRAKE HOSE AT REAR AXLE 800 MM,4 478330
999
BRAKE SHOE , Replaced By: A3414201019
999
BRAKE SHOE , Replaced By: A3414200319
999
BRAKE SHOE , Replaced By: A3414200319
999
BRAKE SHOE , Replaced By: A3414200319
999
BRAKE SHOE , UP TO CHASSIS 910369 ALSO INSTALLED ON 500001-501414,FROM CHASSIS 910370 AND 501415-599999 SEE SPARE PARTS LIST 744.3
999
CUP
999
REPAIR KIT , Replaced By: A3585860242
999
BRAKE SHOE , Replaced By: A3384200019, +002A3524230310, +016A3079900197
999
BRAKE SHOE , Replaced By: A3384200019, +002A3524230410, +016A3079900197
999
BRAKE SHOE , Replaced By: A3534200019, +002A3534232810, +016A3079900197
999
BRAKE INTERMEDIATE SHAFT , Replaced By: A3524201080
999
BEARING BRACKET , UP TO CHASSIS 674067 EXCEPT FOR 500001-599999,673550,673631,673890,673916-673918,673922,673927
999
BEARING BRACKET , 656999
999
LEVER , 656999
999
BRAKE INTERMEDIATE SHAFT REAR
999
BRAKE LEVER , UP TO IDENT NO. 674067 EXCEPT FOR 500001-599999,673430,673630,673576
999
LEVER
999
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT, TO BE ADAPTED DURING ASSEMBLY
999
CONSOLE , 698032
999
CONSOLE , 698032
999
PIN , UP TO CHASSIS 698032 EXCEPT 500001-599999
999
BRACKET BRAKE MASTER CYLINDER
999
BRACKET TRAILER BRAKE VALVE
999
BRACKET METAL SPRING BELLOWS,4 478505
999
SHIM , Replaced By: A3604750484
999
GUIDE SIGN , UP TO CHASSIS 721608 EXCEPTO FOR:500001-599999
999
GUIDE SIGN , FROM CHASSIS 721609-764539 EXCEPT FOR:500001-599999
999
GUIDE SIGN , FROM CHASSIS 764540-932872 ALSO INSTALLED ON 502964-599999
999
GUIDE SIGN LOAD-DEPENDING BRAKE
999
WASHER BRACKET TO CROSS MEMBER,5 434013
999
PIN PISTON ROD TO LEVER, 415 5 014668 416 5 000515 417 4 972023
999
PIN PULL ROD TO BRAKE LEVER,REAR AXLE
999
PIN INTERMEDIATE LEVER
999
REPAIR KIT BRAKE SHOE MOUNTING BOLT
999
REPAIR KIT , Replaced By: A3584200182
999
BRAKE INTERMEDIATE SHAFT , FROM CHASSIS 674068-734559 ALSO INSTALLED ON:673430,673576,673560
999
ROD FROM BRAKE SHAFT TO BRAKE LEVER
999
BRAKE INTERMEDIATE SHAFT , FROM CHASSIS 674068-734559 ALSO INSTALLED ON:673430,673576,673560
999
ROD FROM BRAKE SHAFT TO BRAKE LEVER
999
BRAKE LEVER HAND BRAKE
999
LEVER AT BRACKET, 674067
999
BRAKE INTERMEDIATE SHAFT , FROM CHASSIS 734560 ALSO INSTALLED ON, 500001-599999
999
BRAKE INTERMEDIATE SHAFT , 739560-760179
999
LINE FROM MASTER CYLINDER TO BRAKE PRESSURE REGULATOR 2200 MM
999
LEVER , Replaced By: A3604260611
999
LEVER , Replaced By: A3604260711
999
LEVER RIGHT,2 068748
999
LEVER , 754919
999
LEVER , 753132
999
LEVER , 753132
999
ANGLE LINE MOUNTING
999
BRACKET DISTRIBUTOR
999
BRACKET DISTRIBUTOR
999
CLAMP , Replaced By: N916016008200
999
CONSOLE SPRING LOAD ACCUMULATOR CYLINDER
999
BRACKET , Replaced By: A3604300339
999
SHIM BEARING BRACKET TO FRAME
999
WASHER , Replaced By: A4219905440
999
WASHER ANTE-FREEZE DEVICE TO STRAP
999
WASHER , Replaced By: A3859900440
999
CLAMP FEED LINE TO THERMOSTAT
999
BRACKET DELIVERY AND SUCTION LINES
999
BRACKET , Replaced By: A3812711640
999
WASHER , Replaced By: A3379900440
999
NUT FROM BRAKE SHAFT TO BRAKE LEVER
999
GROMMET LINE MOUNTING 19/13 MM
999
ADHESIVE FOIL GUIDE SIGN
999
WASHER BUMPER BRACKET TO COUPLING MOUTH
999
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
999
SCREW CLAMP MOUNTING M 6X16
999
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
999
SCREW ,374026
999
SCREW LICENSE PLATE TO BRACKET,4 300861
999
SCREW , Replaced By: A0029903712
999
SCREW PROTECTION PLATE TO BRACKET
999
SCREW , UP TO IDENT NO. 674067 EXCEPT FOR 500001-599999, 673432, 673497, 673628,673629,673921
999
COTTER PIN
999
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
999
COTTER PIN VIBRATION ABSORBER TO BRACKET,5 117575
999
COTTER PIN CYLINDER TO BRACKET
999
COTTER PIN STRAP TO CONSOLE
999
COTTER PINTO 345 431 70 16, USED WITH HYDRAULIC BRAKE,345.000-008,021,024,025,033 UP TO IDENT NO. FB588185
999
COTTER PINROCKINGER TYP 260 G140
999
WASHER , Replaced By: N000125010532
999
WASHER RADIATOR TO RUBBER MOUNTING
999
SPRING WASHER SHIFTING ROD TO BRACKET
999
WASHER , Replaced By: N000433010510
999
WASHER VIBRATION ABSORBER TO BRACKET
999
WASHER , Replaced By: N000433013010
999
WASHER PULL ROD TO BRAKE INTERMEDIATE LEVER
999
LOCK RING , UP TO CHASSIS 674067 EXCEPT FOR 500001-599999,673550,673631,673890,673916-673918,673922,673927
999
RIVET
999
SCREW PLUG , Replaced By: N000908012009
999
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
999
SCREW PLUG , Replaced By: N000908022011
999
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
999
SCREW , Replaced By: N304017006027
999
SCREW CLUTCH TO FLYWHEEL
999
SCREW CLAMP TO BRACKET AND TO PIPE
999
SCREW , Replaced By: N304017008021
999
SCREW , Replaced By: N304017008034
999
SCREW BRACKET TO BATTERY/APPARATUS SUPPORT
999
SCREW END PIECE TO EXHAUST PIPE M 10X25
999
SCREW REAR EXHAUST PIPE TO MUFFLER
999
SCREW SUPPORT TO CROSS MEMBER M 10X28
