Поз.
Артикул
Описание
1
INJECTION PUMP ,531415
1
INJECTION PUMP ,531414
1
INJECTION PUMP
30
LEVER
30
LEVER , Replaced By: A3220700122
33
BALL PIVOT
36
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
39
SCREW COVER PLATE TO BRACKET
39
SCREW , Replaced By: N304017006016
39
SCREW PUMP TO BRACKET
42
PULL ROD WIRE CABLE TO TRANSMISSION
44
NUT BALL PIVOT TO LEVER
47
BALL SOCKET PULL ROD TO INTERMEDIATE LEVER
50
SNAP RING SPRING-LOADED PUSH ROD
56
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
999
TAPERED ROLLER BEARING
999
TAPERED ROLLER BEARING
999
INJECTION PUMP , FOR BREAK-DOWN,SEE STANDARD EQUIPMENT MICROFICHE
999
INJECTION PUMP
999
SEAL RING
999
INJECTION PUMP
999
INJECTION PUMP ,530080
999
INJECTION PUMP , Replaced By: A0110748301
999
SEAL RING
999
INJECTION PUMP
999
INJECTION PUMP
999
INJECTION PUMP
999
INJECTION PUMP ,530079
999
INJECTION PUMP
999
INJECTION PUMP , Replaced By: A0110748101
999
INJECTION PUMP , Replaced By: A0110748201
999
INJECTION PUMP
999
SEAL RING
999
INJECTION PUMP
999
INJECTION PUMP
999
SPRING
999
SEAL RINGTO 000 431 59 14
999
SEAL RING
999
SEAL RING OIL LINES TO TRANSMISSION
999
SEAL RINGTO A 012 074 63 02
999
SNAP RING
999
STUD
999
REPAIR KIT
999
PUMP ELEMENT
999
GASKET FUEL PUMP TO INJECTION PUMP, FROM ENGINE 399032 YEAR OF MANUFACTURE 1995
999
SEAL RING
999
SEAL RING
999
SPRING
999
STUD
999
STUD , Replaced By: A0019901105
999
SPRING
999
CLAMPING BRACKET PARTS KIT
999
FILTER BOWL
999
FUEL PUMP (MANUAL FEED PUMP) WITH SEAL RING, FROM ENGINE 399032 YEAR OF MANUFACTURE 1995
999
FUEL PUMP
999
VALVE PARTS KIT TO A 012 074 63 02
999
FILTER ELEMENT , Replaced By: A0000910840
999
FUEL PUMP (MANUAL PUMP) WITH SEAL RING
999
FITTING
999
GASKET
999
WASHER2.50 MM
999
WASHER2.45 MM
999
WASHER2.40 MM
999
WASHER2.35 MM
999
WASHER2.30 MM
999
WASHER2.25 MM
999
WASHER2.20 MM
999
WASHER2.15 MM
999
WASHER2.10 MM
999
WASHER2.05 MM
999
WASHER2.00 MM
999
WASHER1.95 MM
999
WASHER1.90 MM
999
WASHER1.60 MM
999
WASHER1.55 MM
999
WASHER1.50 MM
999
WASHER1.45 MM
999
VALVE ,295838/93
999
WASHER1.40 MM
999
WASHER1.35 MM
999
WASHER1.30 MM
999
WASHER1.25 MM
999
WASHER1.20 MM
999
WASHER1.15 MM
999
WASHER1.10 MM
999
WASHER1.05 MM
999
WASHER1.00 MM
999
SPRING
999
WASHER0.95 MM
999
WASHER0.90 MM
999
WASHER0.85 MM
999
WASHER0.80 MM
999
WASHER0.75 MM
999
WASHER0.70 MM
999
WASHER0.65 MM
999
WASHER0.60 MM
999
WASHER0.55 MM
999
WASHER0.50 MM
999
WASHER0.45 MM
999
WASHER0.40 MM
999
WASHER AS REQUIRED 1.85 MM
999
WASHER1.80 MM
999
WASHER1.75 MM
999
WASHER AS REQUIRED 1.70 MM
999
WASHER AS REQUIRED 1.65 MM
999
SPACER WASHER0.50 MM
999
SEAL RING
999
SPACER WASHER AS REQUIRED 0.30 MM
999
SPACER WASHER0.18 MM
999
TAPPET
999
VALVE
999
CONTROL RACK
999
TAPPET , Replaced By: A0000742429
999
GASKET0.16 MM
999
GASKET AS REQUIRED 0.14 MM
999
GASKET0.12 MM
999
GASKET0.10 MM
999
SLEEVE
999
SPACER WASHER 2.00 MM
999
BEARING
999
SPACER WASHER 1.50 MM
