Поз.
Артикул
Описание
54
ROD (PUSH ROD),SPRING-LOADED
81
NUT
81
NUT SPRING-LOADED PUSH ROD
81
NUT , Replaced By: A0009900851
91
BALL SOCKET , Replaced By: A3669910322
91
BALL SOCKET PULL ROD TO LEVER
91
BALL SOCKET , 364 021704 366 061187
91
BALL SOCKET TO BE EXCHANGED FOR 000 991 24 22
91
BALL SOCKET , 364 021703 366 061186
91
BALL SOCKET
91
BALL SOCKET
91
BALL SOCKET
91
BALL SOCKET
111
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
116
BRACKET RELEASE SPRING
136
BRACKET RELEASE SPRING, UP TO ENGINE 380862 YEAR OF MANUFACTURE 1995
139
SPRING (RELEASE SPRING), UP TO ENGINE 425722 YEAR OF MANUFACTURE 1996
139
SPRING ACCELERATOR CONTROL LINKAGE RELEASE SPRING
141
LEVER (CONTROL LEVER),INJECTION PUMP
141
LEVER (CONTROL LEVER),INJECTION PUMP
141
LEVER CONTROL SHAFT
142
BALL PIVOT
143
BALL PIVOT LEVER
143
BALL PIVOT , Replaced By: A3129910120
156
LEVER (DRAG LINK),CONTROL SHAFT
158
BALL PIVOT , Replaced By: A3129910120
158
BALL PIVOT LEVER
166
LEVER CONTROL SHAFT
166
LEVER CONTROL SHAFT
173
HEXALOBULAR BOLT. SCREW LINE MOUNTING M 6X30
173
SCREW , Replaced By: N000000001479
174
SHAFT (CONTROL SHAFT)
176
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
176
NUT , Replaced By: N913023006001
176
NUT SPRING-LOADED PUSH ROD
189
SPACER TUBE VIBRATION ABSORBER TO BRACKET
189
SPACER TUBE , Replaced By: A4070720353
197
SPACER TUBE , Replaced By: A3210720053
197
SPACER TUBE VIBRATION ABSORBER TO BRACKET 39 MM, TO BE ADAPTED DURING ASSEMBLY
209
SHAFT (CONTROL SHAFT)
209
SHAFT (CONTROL SHAFT)
236
BRACKET IDLING CONTROL
237
SCREENING PLATE , Replaced By: A3660900634
237
SCREENING PLATE ,234537/92
246
BRACKET COOLING WATER EXPANSION TANK
247
SCREW , Replaced By: N304017008021
247
SCREW PIPE CLAMP
254
SCREW , Replaced By: N304017008016
254
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
256
SCREW , Replaced By: N000933008337
256
SCREW , Replaced By: A0099900101
256
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
262
WASHER , Replaced By: N000125008443
262
WASHER EXHAUST MUFFLER TO STRAP
266
SCREW , Replaced By: N304017008040
266
SCREW BRACKET TO SIDE MEMBER
272
BRACKET , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 108103/90, Replaced By: A3660901041
272
BRACKET SCREENING PLATE, FROM ENGINE 234538 YEAR OF MANUFACTURE 1992 UP TO ENGINE 351138 YEAR OF MANUFACTURE 1994
273
CLAMPING SLEEVE INTERMEDIATE SHAFT, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
276
WASHER EXHAUST MUFFLER TO STRAP
276
WASHER , Replaced By: N000125008443
277
SCREW BRACKET TO PLATE
278
LEVER
286
NUT , Replaced By: N913004008001
286
NUT HORN TO BRACKET M8
292
BRACKET CABLE HARNESS MOUNTING, UP TO ENGINE 380862 YEAR OF MANUFACTURE 1995
293
BRACKET CABLE HARNESS MOUNTING, FROM ENGINE 380863 YEAR OF MANUFACTURE 1995
295
SCREW PROPELLER SHAFT TO COUPLING FLANGE
999
CYLINDER , Replaced By: A0000721512
999
CYLINDER CONTROL
999
BUSHING
999
REPAIR KIT POWER CYLINDER TO 000 430 60 26
999
HOSE *** 28 MM, ORDER BY THE METER
999
RADIATOR CAP
999
PLASTIC PIPE AERATION, ORDER BY THE METER
999
BALL SOCKET ACCELERATOR CONTROL
999
LOOM TIE LINE MOUNTING 280 MM
999
RUBBER BUFFER , Replaced By: A1089870240
999
FILLER CAP. RADIATOR CAP
999
CLOSING COVER RADIATOR
999
ROD , NOT USED
999
PAD FEED LINE TO BRACKET
999
LEVER BOWDEN CABLE
999
LEVER (CONTROL LEVER),INJECTION PUMP
999
LEVER
999
BRACKET RELEASE SPRING
999
TANK COOLING WATER EXPANSION TANK
999
BRACKET EXPANSION TANK
999
BRACKET EXPANSION TANK
999
BRACKET EXPANSION TANK
999
LEVER , Replaced By: A3660703821, +001N913017006000, +001N914126006025
999
LEVER , Replaced By: A3660703921, +001N913017006000, +001N914126006025
999
BRACKET REGULATING UNIT
999
LEVER , NOT USED
999
ROD
999
PLATE POWER CYLINDER TO BRACKET
999
BRACKET
999
BRACKET CYLINDER
999
BRACKET START-STOP SWITCH
999
TANK COOLING WATER EXPANSION TANK
999
CONNECTOR
999
ROD , Replaced By: A3660720324
999
ROD
999
ROD , FROM ENGINE 135232 YEAR OF MANUFACTURE 1990
999
HOSE FROM EXPANSION TANK TO THERMOSTAT
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
LOCK RING , FOR USE WITH SHORT VERSION OF MERCEDES-BENZ CAB DISCONTINUED,PART IS NO LONGER REQUIRED
999
SCREW , Replaced By: N304017006018
999
FITTED WASHER AS REQUIRED 1.0 MM
999
GROOVED NAIL BEARING BRACKET TO CYLINDER CRANKCASE
999
BALL PIVOT ROD TO INJECTION PUMP LEVER
999
SCREW COVER PLATE TO COVER PLATE M 6 X 12
999
NUT L.H. THREAD
999
PULL ROD FROM CONTROL SHAFT BEARING TO INTERMEDIATE LEVER 400 MM, TO BE ADAPTED DURING ASSEMBLY
999
SCREW , Replaced By: N914146006102
999
SCREW , Replaced By: N000000001479
999
HEXAGON HEAD BOLT CLAMP AT SUPPORTING RAIL M 8X30
999
NUT HEATING PIPE TO BRACKET
999
SCREW CLAMP MOUNTING M 6X16
999
CLAMP LINE CONNECTION
