Поз.
Артикул
Описание
100
TANK EXPANSION TANK
100
TANK EXPANSION TANK
103
TANK WATER LEVEL SENSOR
104
SENDER UNIT
105
FLOAT
106
GASKET WATER LEVEL SENSOR
109
SCREW. HEXAGON HEAD BOLT RELAY TO BRACKET M5X16
112
BRACKET EXPANSION TANK
118
SCREWM 10X20
121
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
124
SIGHT GLASS COOLING WATER LEVEL CONTROL
127
HOSE ENGINE BREATHING 8X15X2550MM, TO BE ADAPTED DURING ASSEMBLY
130
CLAMP , Replaced By: A0059970190
133
SUPPORTING PLATE
133
SUPPORTING PLATE INSPECTION GLASS
136
CLAMP LINE MOUNTING
139
HEXAGON HEAD BOLT COVERING TO CAB
142
SHEET METAL SCREW TAKE-UP DEVICE, F 136789(COUPE) T 000730(COUPE), T 054271(CABRIO) EXEPT ON VEHICULES WITH CODE 801 ALSO INSTALLED IN VEHICLE FROM T 000731(COUPE), T 054272(CABRI O), F 136790(COUPE) WITH CODE 800
145
FILLER NECK EXPANSION TANK
151
HOSE CONNECTING PIECE,AUXILIARY RADIATOR, ORDER BY THE METER
151
HOSE , ORDER BY THE METER
154
CLAMP
157
CLAMP COOLING WATER HOSES
157
CLAMP CLAMP ON TRANSVERSE SHAFT MOUNTING, LINKAGE
157
CLAMP SAFETY VALVE AT BRACKET
157
CLAMP PIPE ON FAN SHROUD
160
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
166
RADIATOR CAP FILLER NECK
166
RADIATOR CAP , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0005014215
167
CAP OIL FILLING
169
HOSE FROM CONNECTION POINT TO EXPANSION TANK
169
HOSE FROM CONNECTION POINT TO EXPANSION TANK
172
HOSE ENGINE BREATHING 8X15X2550MM, TO BE ADAPTED DURING ASSEMBLY
172
HOSE , Replaced By: N000000000734
175
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
178
CLAMP EXPANSION TANK & COOLING WATER LINE, FROM IDENT-NO. 827712, ALSO INSTALLED IN ENGINE 935766
999
RUBBER BUSHING EXPANSION TANK D50X45MM
