Поз.
Артикул
Описание
3
FRAME
6
FRAME REAR, .......I.......INO.7E87I.......I II
9
BLIND RIVET NUTM8
12
DOOR PULL HANDLE , STATE COLOR NUMBER WHEN ORDERING
15
SCREWM 8X25
18
SEAL
21
SEAL REAR
24
SEGMENT SEAL FRONT
27
SEGMENT SEAL
30
ROLLER CARRIER
33
BRACKET , EXHAUST STOCK OF OLD PART NUMBER FIRST
36
SCREWM8X16
42
GUIDE
45
PLATE
48
RUBBER SEAL TOP
51
SCREW W SOCKET DRIVEM8X20
57
TAPPING SCREW4,2X16
60
HEXALOBULAR BOLT BASIC MODULE AT SUPPORT M6X16,01.08.08
228
GLASS PANE DOUBLE GLAZING,GREEN
228
GLASS PANE SINGLE GLAZING,GREEN
231
GLASS PANE DOUBLE GLAZING,GREEN
231
GLASS PANE SINGLE GLAZING,GREEN
234
ADHESIVE TAPE3900 MM
