S 416 NF - 628.887 - 83 HEATING AND VENTILATION
Поз.
Артикул
Описание
210
DUCT LEFT L7120MM
215
DUCT
220
AIR DUCT LEFT
230
DUCT1850MM
310
DUCT RIGHT L7536MM
315
DUCT
320
AIR DUCT RIGHT
330
DUCT1850MM
810
BRACKET LEFT AND RIGHT
820
BAFFLE
830
BAFFLE
830
BAFFLE LEFT AND RIGHT L4210,3MM
850
DUCT LEFT AND RIGHT
860
DUCT LEFT AND RIGHT
905
BOLT UPPER RIGHT PANELING HOUSING 6X12
910
ADHESIVE TAPE3X50MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
915
RUBBER SEAL. SEALING STRIP LAMP SUPPORT
920
BLIND RIVET. RIVET FAN SHROUD
