Поз.
Артикул
Описание
5
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
5
PLASTIC PIPE RISING PIPE 4X6 MM
10
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
15
UNION NUT
20
SEAL CONE
20
GLAND , Replaced By: A0019901667
25
SLEEVE LEAK LINE
30
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
30
BANJO UNION , Replaced By: N000000000364
30
BANJO UNION HOSE WIDTH, / I.D., 4/14 MM,K 169123
30
BANJO UNION HOSE WIDTH, / I.D., 4/16 MM
30
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
30
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
80
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
105
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
108
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
112
REPAIR KIT. TS SEALING RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
116
CONNECTOR DISTRIBUTOR MIDDLE, COMPRESSED AIR LINE PLUG CONNECTION, WITH THROTTLE
120
SCREW DELIVERY AND SUCTION LINES TO ENGINE, FRONT M 6X35
124
NUT PUMP TO BRACKET
124
NUT , Replaced By: N913004006001
132
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
132
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
132
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
132
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
138
FITTING AIR RESERVOIR,CONNECTIONS: "10,20"
138
FITTING AIR RESERVOIR,CONNECTIONS: "10,20"
140
HOLLOW SCREW HEATING CONNECTION
140
HOLLOW SCREW HEATING CONNECTION
142
SEAL RING LINE CONNECTION
142
SEAL RING LINE CONNECTION
144
SEAL RING LINE CONNECTION
144
SEAL RING LINE CONNECTION
146
SCREW. UNION SCREW LINE CONNECTION
146
SCREW. UNION SCREW LINE CONNECTION
147
PART NAME MISSING. SEAL RING , Replaced By: A0009870446
148
THRUST RING CHECK VALVE TO AIR RESERVOIR
148
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
149
NUT CHECK VALVE TO AIR RESERVOIR
222
SCREW. UNION SCREW LINE CONNECTION
278
VALVE SHUTTLE VALVE, REPAIR IMPOSSIBLE
278
VALVE SHUTTLE VALVE, REPAIR IMPOSSIBLE
278
VALVE SHUTTLE VALVE, REPAIR IMPOSSIBLE
279
VALVE. SHUTTLE VALVE (SHUTTLE VALVE) VOSS
279
VALVE , Replaced By: A0044291544
280
ELBOW FITTING FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
280
ELBOW FITTING FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
283
FITTING LINE CONNECTION
283
FITTING LINE CONNECTION
285
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
285
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
290
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
290
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
290
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
295
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
295
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
295
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
300
SEAL RING FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
300
SEAL RING FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
305
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
305
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
305
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
305
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
310
THRUST RING FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
310
THRUST RING FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
313
FITTING FRONT AXLE II RELAY VALVE,CONNECTION: "24"
313
FITTING FRONT AXLE II RELAY VALVE,CONNECTION: "24"
313
FITTING FRONT AXLE II RELAY VALVE,CONNECTION: "24"
315
HOLLOW SCREW , Replaced By: N915036010108
315
HOLLOW SCREW FUEL LINE TO FEED PUMP
318
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
318
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
320
SEAL RING FUEL LINE TO FEED PUMP
321
NUT CHECK VALVE TO AIR RESERVOIR
323
O-RING CHECK VALVE TO AIR RESERVOIR
324
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
324
THRUST RING CHECK VALVE TO AIR RESERVOIR
325
SCREW. UNION SCREW LINE CONNECTION
328
FITTING SHUTTLE VALVE,CONNECTION: "20",5 727399
328
FITTING SHUTTLE VALVE,CONNECTION: "20"
328
FITTING FROM SHUTTLE VALVE TO 3/2-WAY VALVE
331
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
331
O-RING CHECK VALVE TO AIR RESERVOIR
338
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
338
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
338
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
338
THRUST RING CHECK VALVE TO AIR RESERVOIR
340
NUT CHECK VALVE TO AIR RESERVOIR
340
NUT CHECK VALVE TO AIR RESERVOIR
342
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
342
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
360
SCREW. UNION SCREW LINE CONNECTION
360
SCREW. UNION SCREW LINE CONNECTION
362
HOLLOW SCREW , Replaced By: N915036010108
362
HOLLOW SCREW FUEL LINE TO FEED PUMP
365
BRACKET LOCKING VALVE,5 434013
370
SCREW BRACKET TO SIDE MEMBER
374
SEAL RING FUEL LINE TO FEED PUMP
375
WASHER BRACKET TO CROSS MEMBER,5 434013
380
NUT , Replaced By: N910113010000
380
NUT STRAP TO BRACKET
383
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
385
ADAPTER FITTING , Replaced By: A0069970072
385
FITTING SHUTTLE VALVE,CONNECTION: "20",5 434013
388
O-RING CHECK VALVE TO AIR RESERVOIR
390
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
393
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
393
THRUST RING CHECK VALVE TO AIR RESERVOIR
395
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
400
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
405
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
NUT EXHAUST BRAKE VALVE, CONNECTION: "20"
999
NUT , Replaced By: N913004008001
999
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
PLUG EXHAUST BRAKE VALVE, CONNECTION: "20"
999
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
