Поз.
Артикул
Описание
5
CROSS MEMBER REAR SPRING BRACKET NO.9
5
CROSS MEMBER , Replaced By: A6743101037
8
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
11
WASHER
14
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
14
NUT , Replaced By: N910113012003
20
SPRING BRACKET REAR SPRING FRONT BRACKET
23
SCREWM 14X15X21X38
23
SCREWM 14X15X21X38
32
NUT , Replaced By: N910113014000
32
NUT STEERING SUPPORT TO FRAME
32
NUT STEERING SUPPORT TO FRAME
35
CONSOLE BODY MOUNTING
47
CROSS MEMBER REAR SHOCK ABSORBERS NO.5
53
CONSOLE TORSION BAR,REAR
56
BEARING TORSION BAR BEARING
62
CONSOLE , Replaced By: A6733171101
62
CONSOLE BODY MOUNTING
77
SPRING BRACKET REAR-SPRING REAR BRACKET
80
BUSHING SPRING EYE,REAR
83
SCREWM 14X15X17X34
83
SCREWM 14X15X18X35
86
NUT STEERING SUPPORT TO FRAME
86
NUT , Replaced By: N910113014000
999
WASHER , Replaced By: N006902011100
999
SCREW END PIECE TO EXHAUST PIPE M 10X25
999
WASHER , Replaced By: N006902011102
999
WASHER UNDERRUN PROTECTION AND BRACKET TO FRAME
999
NUT STRAP TO BRACKET
999
NUT , Replaced By: N910113010000
