Поз.
Артикул
Описание
8
RESERVOIR AIR RESERVOIR 40L 246X915MM
10
RESERVOIR142PSI/60L
16
VALVE BRAKE CIRCUIT II, AND SPRING LOAD ACCUMULATOR
25
REDUCTION FITTING. LOCK NUT BRAKE CIRCUIT II, AND SPRING LOAD ACCUMULATOR
45
STRAP780LG
45
STRAP875LG
46
BRACKET AIR RESERVOIR
48
BRACKET AIR RESERVOIR OBEN
49
BRACKET AIR RESERVOIR UNTEN
50
SHACKLE
51
SPACER BUSH15X9X11LG.
55
SUPPORT
57
BRACKET
999
CLIP
999
METAL SECTION , ORDER BY THE METER
999
FITTING AT AIR RESERVOIR
999
FITTING AT AIR RESERVOIR, Replaced By: N210500000011
999
FITTING AT AIR RESERVOIR
999
PLUG OIL PRESSURE GAUGE
999
PLUG REGENERATION TANK BR 0,6MPT
999
WASHER HAND BRAKE VALVE 1/4
999
WASHER FRONT SPRINGS TO FRONT AXLE 3/4
999
NUT AIR COMPRESSOR LINE 1/4X20
999
SCREW1/4 - 20
999
SCREW BRAKE LINE TO CROSS MEMBER5/16 - 18
999
CLAMP , Replaced By: QT01-27263-000
999
SCREW AIR RESERVOIR TO BRACKET 3/8-16
999
PART NAME MISSING SCREW
999
VALVE PRESSURE CONTROL VALVE
