Поз.
Артикул
Описание
5
FUEL TANK TO BE MOUNTED ON THE LEFT 300 L, UP TO: 04.98
10
SCREW PLUG FUEL DISCHARGE
15
SEALING RING. SEAL RING FUEL TANK
20
FILLER CAP ,K 057755
25
SEAL RING
30
TUMBLER WITH KEY, ANY LOCK,K 057755
35
TUMBLER WITH LOCK DEFINED, STATE LOCK NUMBER WHEN ORDERING
40
KEY BLANK, STATE LOCK NUMBER WHEN ORDERING
45
VALVE (VENT VALVE)
45
VALVE , Replaced By: A0004705193
55
PLUG BREATHER VALVE
60
LOCK FUEL GAUGE SENDER UNIT CONNECTION
65
SUPPORT FUEL TANK TO FRAME
65
SUPPORT FUEL TANK TO FRAME
75
HEXAGON HEAD BOLT. SCREW BRACKET TO CONSOLE
80
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
85
STRAP FUEL TANK TO CONSOLE
90
PIN STRAP TO SUPPORT
90
PIN , Replaced By: A9444750074
95
CLIP RESERVOIR TO CAB FRONT PANEL
100
NUT STRAP TO SUPPORT M12X1.5
105
PAD STRAP 61 MM
110
PAD BRAKE ANCHOR 53 MM
120
PLASTIC PIPE FUEL LINE 3X5MM, ORDER BY THE METER
125
FITTING (PARTS KIT),LINE RUPTURE
130
CONNECTOR BREATHER LINE CONNECTION
135
SEAL RING FUEL GAUGE SENDER UNIT CONNECTION
140
LOCK FUEL GAUGE SENDER UNIT CONNECTION
145
HOLLOW SCREW FUEL LINE TO FEED PUMP
150
SEAL RING CLUTCH BOOSTER
155
BRACKET FUEL LINE
160
BRACKET FUEL LINE
165
CLAMP , Replaced By: A1109950401
170
CLAMP LINE CONNECTION
175
RUBBER PAD FUEL LINE TO BRACKET
180
SCREW MOUNTING OF INSTRUMENT PANEL
185
NUT RELAY TO BRACKET M5
999
LINE FUEL COMPENSATING
