Поз.
Артикул
Описание
5
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
5
HOSE , Replaced By: A0009872827
7
UNION NUT LINE CONNECTION
7
UNION NUT LINE CONNECTION, Replaced By: N000000006239
9
SEAL CONE LINE CONNECTION
9
GLAND , Replaced By: A0019901967
11
BUSHING , Replaced By: N915062009000
11
SLEEVE LINE CONNECTION
13
FITTING ,4 261891
17
BRACKET
23
SCREW END PIECE TO EXHAUST PIPE M 10X25
29
WASHER RADIATOR TO RUBBER MOUNTING
29
WASHER , Replaced By: N000125010532
42
RESERVOIR E P S AND CLUTCH BOOSTER 10 L, Replaced By: A0034320801
42
RESERVOIR COMPRESSED AIR 10 L.
50
ELBOW FITTING AIR RESERVOIR,CONNECTIONS: "31,32"
54
NUT CHECK VALVE TO AIR RESERVOIR
70
THRUST RING CHECK VALVE TO AIR RESERVOIR
70
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
74
O-RING CHECK VALVE TO AIR RESERVOIR
78
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
78
SCREW PLUG , Replaced By: N000908022011
82
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
82
THRUST RING CHECK VALVE TO AIR RESERVOIR
86
O-RING CHECK VALVE TO AIR RESERVOIR
94
STRAP AIR RESERVOIR
98
NUT BRACKET TO SUPPORT AND TO END PIECE
102
BASE AIR RESERVOIR
106
CYLINDRICAL PIN
106
CYLINDRICAL PIN , Replaced By: N000007006203
120
VALVE DRAIN, Replaced By: A0004322107
120
VALVE DRAIN, Replaced By: A0004322407
120
VALVE. DRAIN VALVE DRAIN
124
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
124
THRUST RING CHECK VALVE TO AIR RESERVOIR
128
O-RING CHECK VALVE TO AIR RESERVOIR
132
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
132
SCREW PLUG , Replaced By: N000908022011
136
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
136
THRUST RING CHECK VALVE TO AIR RESERVOIR
140
O-RING CHECK VALVE TO AIR RESERVOIR
999
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
999
BASE STRAP
999
ELBOW FITTING AT BRAKE BOOSTER
