Поз.
Артикул
Описание
5
SCREENING BOOT TO STEERING
14
SCREENING FIRE WALL,LEFT
17
SCREENING STEERING
26
SCREW , Replaced By: A2039900036
33
SCREENING SUBFRAME,LEFT
38
SCREENING FIRE WALL,RIGHT, NO LONGER AVAILABLE
44
COMBINATION BOLT , FROM CHASSIS 123.033 041774
47
NUT , Replaced By: A2109900150
47
HEXAGON NUT W COLLAR BRACKET MOUNTING
56
LOCK INSTRUMENT PANEL TO PANELLING
59
TAPPING SCREW
59
SCREW , Replaced By: A2039900036
65
SCREENING TO BATTERY SUPPORT POINT
71
LOCK INSTRUMENT PANEL TO PANELLING
74
COMBINATION BOLT TO BATTERY SUPPORT POINT
77
SCREENING LEFT FRONT SIDE MEMBER
78
SCREW , Replaced By: A2039900036
80
HEXAGON NUT W COLLAR BRACKET MOUNTING
80
NUT , Replaced By: A2109900150
83
SCREENING RIGHT FRONT SIDE MEMBER
86
COMBINATION BOLT , FROM CHASSIS 123.033 041774
89
NUT , Replaced By: A2109900150
89
HEXAGON NUT W COLLAR BRACKET MOUNTING
92
SCREENING MAIN FLOOR,FRONT LEFT
95
HEXAGON NUT W COLLAR BRACKET MOUNTING
95
NUT , Replaced By: A2109900150
98
SCREENING MAIN FLOOR ABOVE CATALYST
104
HEXAGON NUT W COLLAR BRACKET MOUNTING
104
NUT , Replaced By: A2109900150
104
NUT , Replaced By: A2109900150
110
SCREENING MAIN FLOOR ABOVE CATALYST
113
NUT , Replaced By: A2109900150
113
NUT , Replaced By: A2109900150
113
HEXAGON NUT W COLLAR BRACKET MOUNTING
116
SCREENING ABOVE POSTERIOR MUFFLER
119
HEXAGON NUT W COLLAR BRACKET MOUNTING
119
NUT , Replaced By: A2109900150
119
NUT , Replaced By: A2109900150
122
SCREENING TAIL PIPE
125
NUT , Replaced By: A2109900150
125
HEXAGON NUT W COLLAR BRACKET MOUNTING
128
LOCK , Replaced By: A1299940845
131
COMBINATION BOLT , FROM CHASSIS 123.033 041774
