Поз.
Артикул
Описание
10
REAR FENDER RIGHT
10
REAR FENDER LEFT
10
REAR FENDER RIGHT, Replaced By: A2206301021
15
PANELLING RIGHT
15
PANELLING LEFT
17
PANELLING LEFT REAR FENDER, ONLY FOR SECTIONAL REPAIR WORK
17
PANELLING RIGHT REAR FENDER, ONLY FOR SECTIONAL REPAIR WORK
20
TAKE-UP DEVICE LEFT, Replaced By: A2206300989
20
TAKE-UP DEVICE RIGHT, Replaced By: A2206300889
20
TAKE-UP DEVICE RIGHT, Replaced By: A2206301089
20
TAKE-UP DEVICE LEFT
20
TAKE-UP DEVICE RIGHT
30
BOTTOM LEFT REAR FENDER
30
BOTTOM RIGHT REAR FENDER
40
FLAP BREATHER TO REAR FENDER IN BUMPER AREA
50
FLAP FUEL FILLER NECK
60
SPRING FILLER NECK FLAP
70
SCREW CONDENSER TO CHARGE AIR INTERCOOLER M6 X 12
90
HOSE TANK FILLER NECK DRAIN PIPE
100
CLIP
110
INTERMEDIATE LAYER SCUFF GUARD BETWEEN FENDER AND BUMPER, LEFT
110
INTERMEDIATE LAYER ANTI-CHAFE PROTECTION BETW. FENDER AND BUMPER, A 00241820080530
120
COVER LEFT REAR FENDER
120
COVER RIGHT REAR FENDER
125
LOCK NUT CENTER REINFORCEMENT TO HOUSING CENTER CONSOLE 4.8/0.5-2.5 MM
130
PLASTIC NUT. NUT
200
BLIND RIVET REPAIR SOLUTION 6,4 X 12MM / 1-3,5MM, NO LONGER AVAILABLE RIVET ONLY VALID FOR BR222. REPAIR INFORMATION SEE WIS. ADDITIONAL INFORMATION ON TECHNICAL MARKET SUPPORT
