Поз.
Артикул
Описание
197
SCREW , Replaced By: A1249902101
197
SCREW BRACKET TO THROTTLE HOUSING
197
SCREW DRIVE CONNECTION BETWEEN ENGINE AND TRANSMISSION
209
LINE BREATHER
209
LINE BREATHER
209
LINE BREATHER
213
HOSE LEAK LINE, ORDER BY THE METER
217
HOLLOW SCREW OIL LINE
221
SEAL RINGTO 001 431 72 14
221
SEAL RING RELAY VALVE,CONNECTION: "41"
222
WASHER , Replaced By: N000125008443
222
WASHER BREATHER
222
WASHER EXHAUST MUFFLER TO STRAP
223
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
223
SCREW , Replaced By: A0099900101
223
SCREW , Replaced By: N000933008337
225
LINE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4602701096
225
LINE , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO.:655713, Replaced By: A3092702796
225
LINE , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A3092702596
225
LINE , Replaced By: A1232702296
225
LINE FROM TRANSMISSION TO OIL COOLER,LEFT
225
LINE FROM TRANSMISSION TO OIL COOLER 10X1 MM
225
LINE FROM TRANSMISSION TO OIL COOLER,LEFT
225
LINE FROM TRANSMISSION TO OIL COOLER,LEFT, SIMPLE PART-PLEASE HAVE SHOP MADE
225
LINE FROM TRANSMISSION TO OIL COOLER,LEFT
225
LINE FROM TRANSMISSION TO OIL COOLER,LEFT
225
LINE FROM TRANSMISSION TO OIL COOLER,LEFT
229
LINE FROM TRANSMISSION TO OIL COOLER,RIGHT,655714
229
LINE FROM TRANSMISSION TO OIL COOLER,RIGHT
229
LINE FROM TRANSMISSION TO OIL COOLER,RIGHT
229
LINE FROM TRANSMISSION TO OIL COOLER,RIGHT
229
LINE FROM TRANSMISSION TO OIL COOLER,RIGHT
229
LINE FROM TRANSMISSION TO OIL COOLER,LEFT
229
LINE FROM TRANSMISSION TO OIL COOLER,RIGHT
229
LINE FROM TRANSMISSION TO OIL COOLER,RIGHT
229
LINE , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. 715267, Replaced By: A6012700896
229
LINE FROM TRANSMISSION TO OIL COOLER,LEFT,655714
229
LINE FROM TRANSMISSION TO OIL COOLER,RIGHT
229
LINE FROM TRANSMISSION TO OIL COOLER,RIGHT 1020 MM
229
LINE , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO.:557658, Replaced By: A6012700496
229
LINE , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO.:557658, Replaced By: A6012700596
229
LINE , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO ENGINE 001498, Replaced By: A4602701196
229
LINE , Replaced By: A6012700496
229
LINE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4602700996
229
LINE , THE OLD PART MUST NO LONGER BE INSTALLED THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6012700496
229
LINE , Replaced By: A4602700396
229
LINE , Replaced By: A3092702496
229
LINE , Replaced By: A6012700596
229
LINE , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO.:655713, Replaced By: A3092702896
229
LINE , Replaced By: A6012701196
229
LINE , Replaced By: A6012705096
229
LINE , Replaced By: A6012700596
233
SCREW , Replaced By: N304017010050
233
SCREW , Replaced By: N304017010055
233
SCREW CLUTCH TO FLYWHEEL
233
SCREW BRACKET TO TRANSMISSION,4 411810
237
WASHER RADIATOR TO RUBBER MOUNTING
237
WASHER , Replaced By: N000125010532
241
SPRING WASHER STEERING COLUMN BRACKET TO CAB
245
NUT BRACKET TO SUPPORT AND TO END PIECE
247
BRACKET CONVERTER HOUSING
247
BRACKET CONVERTER HOUSING
248
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
249
HOLLOW SCREW OIL LINE TO CONVERTER HOUSING
253
SEAL RING COMPRESSED AIR LINE TO PARKING BRAKE VALVE
257
HOSE FROM TRANSMISSION TO OIL COOLER
257
HOSE , Replaced By: A0159977082
257
HOSE , Replaced By: A0159977082
261
HOSE , Replaced By: A0189975782
261
HOSE , Replaced By: A0189975582
261
HOSE , Replaced By: A0199978182
261
HOSE OIL LINE CONNECTION
261
HOSE FROM ENGINE JUNCTION TO OIL COOLER
261
HOSE FROM ENGINE JUNCTION TO OIL COOLER, FROM IDENT NO. 556500 ALSO INSTALLED ON 543411,543418,551588,551771,552021,552392,552551,552654,552687,552840,552846,553000,553005,553105, 553112,553264,553332,554081,554103,554213,554266,554270,554993,555186,555885,555992,556138,556169, 556181,556184,556187,556189,556194-556197,556215.
268
BRACKET OIL LINES TO ENGINE
268
BRACKET OIL LINES TO ENGINE
271
BRACKET OIL LINES TO ENGINE
274
SPACER TUBE OIL LINES TO ENGINE
277
SCREW SHIM TO LEAF SPRING
277
SCREW BEARING BRACKET TO TRANSMISSION
277
SCREWROCKINGER,TYP 59 U150
277
SCREW
277
SCREW OIL LINES TO ENGINE M 6X60
277
SCREW , Replaced By: A0019907212
277
SCREW , Replaced By: N000912006175
277
SCREW , Replaced By: A0009847929
280
SPRING WASHER LICENSE PLATE TO BRACKET
283
NUT BALL PIVOT TO LEVER
286
CLAMP OIL LINE TO CONVERTER HOUSING
290
SCREW RUBBER BUFFER TO SPRING LEAF
290
SCREW OIL LINES TO ENGINE M 6X70
290
SCREW
290
SCREWM 6X16
290
SCREW OIL LINES TO ENGINE,001498
290
SCREW BEARING BRACKET TO TRANSMISSION
294
LOCK WASHER BATTERY BASE FRAME TO BATTERY/APPARATUS SUPPORT
296
WASHER , Replaced By: A6170720151
296
SPACER RING DE-AERATION LINE TO BRACKET
298
BUSHING OIL LINES TO ENGINE,001498
298
SPACER TUBE OIL LINES TO ENGINE
306
GROMMET OIL LINE TO CONVERTER HOUSING
310
CLAMP OIL LINE TO CONVERTER HOUSING
314
SCREWM 6X16
314
SCREW BEARING BRACKET TO TRANSMISSION
318
SPRING WASHER LICENSE PLATE TO BRACKET
322
GROMMET OIL LINE TO CONVERTER HOUSING,313761
322
GROMMET OIL LINE TO CONVERTER HOUSING
999
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
999
SPRING WASHER , Replaced By: N000137008212
999
WASHER , Replaced By: N000125008443
999
WASHER
