Поз.
Артикул
Описание
10
14
FLANGE GASKET , Replaced By: A3024900080
14
FLANGE GASKET , Replaced By: A4424920080
14
FLANGE GASKET FRONT EXHAUST PIPE TO EXHAUST MANIFOLD, ELIMINATED - NO LONGER REQUIRED
18
SCREW FRONT EXHAUST PIPE TO EXHAUST MANIFOLD M 12 X 90
22
SPACER TUBE FRONT EXHAUST PIPE TO EXHAUST MANIFOLD
26
NUT CONNECTOR TO EXHAUST MANIFOLD
40
50
55
CLAMP EXHAUST PIPE,4 726045
65
70
BRACKET FEED AND RETURN LINES TO RETARDER 110 MM LANG, TO BE ADAPTED DURING ASSEMBLY
72
CLAMP EXHAUST PIPE,4 726045
80
CLAMP BRACKET TO ACCUMULATOR
90
100
102
134
CLAMP EXHAUST PIPE,4 726045
140
140
999
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
999
999
SPACER TUBE , Replaced By: A3179911040
999
999
999
BRACKET
999
999
999
999
999
999
999
999
999
999
999
999
WASHER , Replaced By: N000125008443
999
WASHER EXHAUST MUFFLER TO STRAP
999
WASHER , Replaced By: N000125010532
999
WASHER RADIATOR TO RUBBER MOUNTING
999
LOCK WASHER COVER PLATE AND BASE FRAME TO RADIATOR BLOCK
999
SCREW CONNECTOR TO EXHAUST MANIFOLD
999
SCREW , Replaced By: N000933008337
999
SCREW CLAMP TO BRACKET AND TO PIPE
999
SCREW , Replaced By: A0099900101
999
SCREW END PIECE TO EXHAUST PIPE M 10X25
999
SCREW SUPPORT TO CROSS MEMBER M 10X28
999
NUT BRACKET TO SUPPORT AND TO END PIECE
999
NUT STRAP TO SUPPORT
999
SCREW , Replaced By: N308676012012
999
SCREW BRACKET TO LEFT SIDE MEMBER
999
SCREW FRONT AXLE REGULATING SOLENOID VALVE M 8X75
999
SCREW , Replaced By: N304014008001
999
NUT
999
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
LOCK WASHER FITTING TO BRACKET
