Поз.
Артикул
Описание
8
DRAIN COCK CONNECTOR
16
BRACKET OIL COOLER
16
BRACKET OIL COOLER
16
BRACKET OIL COOLER
24
BRACKET
32
CLAMP
40
SCREW BRACKET TO CROSS CONNECTION STRUT
40
SCREW , Replaced By: N304017008034
48
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
56
NUT
56
NUT , Replaced By: N304032008006
64
SCREW BRACKET TO SIDE MEMBER,5 105538
72
LOCK WASHER FITTING TO BRACKET
80
NUT BRACKET TO TRANSMISSION
88
SEAL RING AT AIR COMPRESSOR
96
FITTING
108
OIL LINE .
108
OIL LINE .
116
OIL LINE FROM OIL COOLER TO TRANSMISSION
116
OIL LINE FROM OIL COOLER TO TRANSMISSION
124
SEALING RING. SEAL RING DELIVERY LINE TO STEERING
132
SCREW. BANJO BOLT AIR RESERVOIR,CONNECTION: "33",4 872664
132
HOLLOW SCREW FUEL FEED,AT WATER SEPARATOR
140
SEAL RING VALVE TO VALVE,K 025179
148
DOUBLE FITTING OIL LINE TO OIL COOLER AND TO TRANSMISSION
156
PIPE SOCKET
164
HOSE
164
HOSE35X43X100 MM
172
CLAMP , Replaced By: N000000000670
172
CLAMP SUCTION LINE TO OIL PUMP 40-60X13 MM
172
CLAMP , Replaced By: N000000000671
180
PIPE SOCKET
180
PIPE SOCKET
999
LOOM TIE
999
LOOM TIE , Replaced By: N916017040000
999
PIPE SOCKET
999
PIPE ELBOW
999
PIPE ELBOW
999
OIL COOLER
999
UNION NUT
