Поз.
Артикул
Описание
50
OIL FILLER NECK WITH BREATHER PIPE
53
OIL DIPSTICK
56
GUIDE TUBE , 910,914,915,951 FROM ENGINE 043951 EXCEPT FOR 043994,043999 CONTINUED,SEE FOOTNOTE 61 ON REPLACEMENT FOR 326 010 02 66,REWORK HOLE SPACING FROM 37MM TO 40MM
59
OIL PUMP LESS SUCTION PIPE
59
OIL PUMP
62
HOUSING
62
HOUSING
65
OIL PUMP SHAFT
68
DRIVE SHAFT
68
DRIVE SHAFT
71
HOUSING
74
GEAR DRIVING, 001571
77
GEAR DRIVEN, 001571
80
COVER
83
SEAL RING LINE CONNECTION
86
SCREW PLUG RELAY VALVE,CONNECTIONS: "23"
86
SCREW PLUG AT TANK
89
BRACKET
92
CLAMP SUCTION PIPE TO BRACKET
95
SCREW , Replaced By: N304017008016
95
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
98
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
101
NUT
101
NUT , Replaced By: N304032008006
104
PIPE
107
SUCTION PIPE
107
SUCTION PIPE , Replaced By: A3461800852
110
BRACKET
113
BRACKET
116
CLAMP
119
SCREW CLAMP TO BRACKET AND TO PIPE
119
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
119
SCREW , Replaced By: N304017008016
122
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
125
NUT
125
NUT , Replaced By: N304032008006
128
GASKET , Replaced By: N917003026003
128
SEAL. GASKET , Replaced By: A3661880880
131
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
134
SCREW PIPE CLAMP
134
SCREW , Replaced By: N304017008021
137
SCREW BEARING TUBE TO CLUTCH HOUSING, UP TO CHASSIS 679695
137
SCREW BRACKET TO TRANSMISSION
140
CONNECTOR
143
GASKET OIL FILTER TO CYLINDER CRANKCASE
143
GASKET , Replaced By: A3551840680
146
HEX. HEAD. SCREW FLANGE TO EXHAUST MANIFOLD
149
SPACER TUBE
152
HOSE *** 55 X 67 X 90 MM
155
CLAMP
158
NUT ARTICULATED ROD TO LEVER
999
LOOM TIE , Replaced By: N916017050000
999
OIL PAN
999
SUCTION PIPE
999
GASKET GUIDE TUBE TO OIL PAN
999
SUCTION PIPE
999
OIL PUMP SHAFT
999
GUIDE TUBE ,000501 910,914,915 UP TO ENGINE 043950 ALSO INSTALLED ON 043994,043999,SEE FOOTNOTE 59, Replaced By: A3550100466, +001A3550101172
999
BREATHER PIPE
999
OIL DIPSTICK
999
OIL FILLER NECK
999
OIL PAN
999
FLANGE TO LOCK OIL FILLER FLANGE,BOTTOM
999
GASKET OIL FILLER NECK TO OIL PAN
999
SCREW ,058651
999
SCREW PLUG , Replaced By: A4039970230
999
OIL DIPSTICK
999
OIL DIPSTICK
999
SUCTION PIPE
999
OIL PUMP SHAFT
999
FLANGE
999
STUD SHIFT CASE TO 352 260 12 14,352 260 17 14,4 473926 FROM IDENT NO. SEE MICROFICHE MODEL 714.0 FROM IDENT NO. SEE MICROFICHE MODEL 714.0
999
NUT , Replaced By: N304032008006
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
SCREW PLUG RELAY VALVE,CONNECTION "20",RIGHT
999
THREADED PIN
999
THREADED INSERT FROM ENGINE TO CONNECTION HOSE, FEED,003426
