Поз.
Артикул
Описание
5
PANELLING TUNNEL COVERING WITH TRAY
5
PANELLING TUNNEL COVERING WITH TRAY
8
INSTRUMENT PANEL UPPER PART, B 065821 F 122352
8
INSTRUMENT PANEL UPPER PART,NO.9045I NO.5070I NO.8310I NO.8317I NO.8317I NO.6093 AI NO.9045I NO.7102I I NO.6121 BI
11
PLATE
14
CONSOLE
17
SCREW COVER PLATE TO COVER PLATE M 6 X 10
17
SCREW , Replaced By: N304017006034
20
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
20
WASHER COMPRESSED AIR LINE TO BRACKET
23
COVERING
23
COVERING , Replaced By: A1246802736
26
COVERING
29
SCREW
29
SCREW , Replaced By: N000000001812
32
PANELLING
35
PIN
38
SCREW
38
SCREW , Replaced By: N000000001812
41
COVER ,F 063052, Replaced By: A1246804089, +001A1246830710
41
COVER LATERAL RIGHT
41
COVER LATERAL LEFT
41
COVER ,F 063052, Replaced By: A1246803989, +001A1246830710
44
COVER
47
PANELLING CENTRAL
50
SHEET METAL SCREW SHIFT LEVER BEARING TO CAB FLOOR
51
BRACKET ,F 029921
52
SHEET METAL SCREW
52
SHEET METAL SCREW , Replaced By: N007981003214
53
LOCK AT BRACKET,F 029921
53
LOCK , Replaced By: A0029946845
54
SHEET METAL SCREW CENTRAL HOUSING TO BRACKET 3.5X22,F 029921, Replaced By: N000000000479
54
SHEET METAL SCREW , Replaced By: N007982003260
54
TAPPING SCREW CENTRAL HOUSING TO BRACKET 3.5X22,F 029921
55
LOCK WINDOW FRAME TO DOOR
56
SHEET METAL SCREW HOUSING TO TUNNEL COVERING 4.2X45
59
LOCK WINDOW FRAME TO DOOR
59
LOCK , Replaced By: A1239942045
62
LINING HOUSING,BOTTOM LEFT VELOURS,NO.7145I NO.5088I NO.8E42I NO.8423I NO.8424I NO.6129I NO.3117I NO.7144I IIIIIIII
62
LINING HOUSING,BOTTOM RIGHT VELOURS,NO.7145I NO.5088I NO.8E42I NO.8423I NO.8424I NO.6129I NO.3117I NO.7144I IIIIIIII
65
COVERZEBRANO
65
COVERING , Replaced By: A1246804489, +001A1246803989, +001A1246804089, +001A1246830306, +001A1246830710
68
ASHTRAY
71
BRACKET ASHTRAY TO TRAY
74
RECESS CIGAR LIGHTER
77
CIGAR LIGHTER
80
SLEEVE
