Поз.
Артикул
Описание
6
PUMP ROTATING CLOCKWISE
14
PLUG *** R3/8"
22
PLUG
30
VALVE
38
GREASE NIPPLE PROTECTIVE TUBE
46
STUD BOLT
54
NUT
54
NUT , Replaced By: N304032008006
62
SEAL RING
70
SEAL RING
78
RADIAL SEAL RING
86
BALL BEARING FRONT
94
SHAFT
102
WOODRUFF KEY POWER STEERING PUMP
110
KEY
118
IMPELLER
126
LOCK
134
NUT
142
WASHER
150
GASKET FRONT
158
INTERMEDIATE PIECE
166
GASKET CENTRAL
174
SEAL RING
182
SEAL RING
190
THREADED UNION
198
SEAL RING
206
WASHER
214
GROOVED BALL BEARING
222
NUT , Replaced By: N000979016007
222
NUT SHOCK ABSORBER TO CROSS MEMBER
230
COTTER PIN
238
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
246
NUT BRACKET TO SUPPORT AND TO END PIECE
254
THREADED PIN
262
COVER FRONT
270
SCREW
278
COVER REAR
286
SEAL RING FUEL LINE TO FEED PUMP
294
COTTER PIN
714
ANGLE
730
PIPE
738
FLANGE
999
SCREW
999
FLANGE
999
FLANGE
999
SUPPORT
999
SHAFT
999
BEARING
999
SEAL RING
999
GASKET
999
SEAL RING MAJOR
999
SEAL RING MINOR
999
SEAL RING OUTSIDE
999
SEAL RING
999
SEAL RING
999
SEAL RING
999
STUD BOLT
999
NUT M14X1,5 MM
999
PLUG , Replaced By: A8469970101
999
PLUG , Replaced By: A8469970201
999
DRAIN COCK , Replaced By: A8469973836
