Поз.
Артикул
Описание
10
TURBOCHARGER
10
TURBOCHARGER MAKE KKK
10
TURBOCHARGER
10
TURBOCHARGER MAKE KKK, ORDER NUMBER: 352 096 56 99/34
10
TURBOCHARGER MAKE AIRESEARCH, 352.900-008-002106
14
SCREW , Replaced By: A0000960470
14
STUD MAKE AIRESEARCH
15
REPAIR KIT TURBOCHARGER,MAKE KKK TO 352 096 57 99
15
REPAIR KIT TURBOCHARGER,MAKE AIRESEARCH
15
REPAIR KIT , Replaced By: A0000900598
18
COMPRESSOR WHEEL MAKE AIRESEARCH
21
TURBINE WHEEL MAKE AIRESEARCH
24
THRUST WASHER MAKE AIRESEARCH
27
REPAIR KIT MAKE KKK,MOVING PARTS TO 352 096 18 99
27
RUNNER MAKE KKK,MOVING PARTS TO 352 096 71 99
27
REPAIR KIT TURBOCHARGER MOVING PARTS,MAKE KKK TO 352 096 57 99
34
ELBOW AIR
34
ELBOW FROM TURBOCHARGER TO CYLINDER HEAD COVER
36
ELBOW AIR
38
GASKET COMPRESSED AIR ELBOW TO TURBOCHARGER
38
GASKET
40
GASKET
42
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
42
SCREW AIR COMPRESSOR TO SUPPORT M 8X35
42
SCREW , Replaced By: N304017008027
46
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
46
SPRING WASHER , Replaced By: N000137008212
50
NUT , Replaced By: N304032008006
50
NUT
52
SCREW PLUG STABILIZER
54
HOSE COOLING WATER LINE TO PIPE SOCKET
54
HOSE
54
HOSE (MOLDED HOSE)
58
CLAMP , Replaced By: N000000000673
58
CLAMP , Replaced By: N000000000672
58
CLAMP , Replaced By: N000000000671
58
CLAMP HOSE TO RETARDER 60-80X13 MM
58
CLAMP HOSE FASTENING 50-70X13 MM
58
CLAMP SUCTION LINE TO OIL PUMP 40-60X13 MM
62
ELBOW
62
ELBOW FROM CYLINDER HEAD COVER TO TURBOCHARGER
66
GASKET , Replaced By: A3520160380
66
GASKET CONNECTION TO CYLINDER HEAD COVER,352.900-007-000691
68
SCREW REAR EXHAUST PIPE TO MUFFLER
72
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
76
NUT BRACKET TO SUPPORT AND TO END PIECE
85
SCREENING PLATE
85
SCREENING PLATE
90
EXHAUST MANIFOLD
90
EXHAUST MANIFOLD , Replaced By: A3521402709
90
EXHAUST MANIFOLD
96
STUD BOLT BRACKET TO CYLINDER BLOCK, REAR,5 171760
96
STUD AT AIR BRAKE BOOSTER,145737 ALSO INSTALLED ON 139841,139842,140553,145397,145406,145409,145426,145445,145462,145592,145660,145697,145701. EXCEPT FOR 145741,145768,145770,145774,145786,145787,145795,145807,145808,145819,145825,145830,145837,145840, 145846,145860,145861,145888,145901,145907,145910,145911,145913-145917,146138.
101
GASKET , Replaced By: A3521420480
101
GASKET EXHAUST MANIFOLD
106
CLAMPING PIECE , Replaced By: A3521420912
106
CLAMPING PIECE
110
SCREW
110
SCREW PRESSURE LIMIT VALVE TO BRACKET M 10X115
116
GASKET TURBOCHARGER TO EXHAUST MANIFOLD
120
NUT POWER CYLINDER TO BRACKET
120
NUT CONNECTING PIPE TO EXHAUST BRAKE
120
NUT , Replaced By: A0009903250
124
FITTING OIL RETURN LINE TO EXHAUST GAS TURBOCHARGER
125
SEAL RING VALVE TO VALVE,K 025179
138
OIL LINE TURBOCHARGER
138
OIL LINE TURBOCHARGER OIL RETURN, 352.900-008-002106
138
OIL LINE OIL RETURN
138
OIL LINE RETURN
141
HOSE , Replaced By: A0005514156
141
HOSE
141
HOSE FUEL COMPENSATING, ORDER BY THE METER
144
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
144
CLAMP , Replaced By: N000000000667
144
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
147
GASKET , Replaced By: A4421870080
147
GASKET OIL RETURN LINE TO TURBOCHARGER
147
SEAL. GASKET , Replaced By: A3661880880
150
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
153
SCREW BRACKET TO APPARATUS SUPPORT
153
SCREW , Replaced By: A0069909301
999
HOLLOW SCREW
999
SEALING RING. SEAL RING DELIVERY LINE TO PUMP
999
SCREW PLUG
999
GASKET , Replaced By: A4421870180
999
OIL COOLER
999
OIL COOLER , Replaced By: A3621800965
999
GASKET OIL COOLER TO CYLINDER CRANKCASE,730881
999
OIL COOLER , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO ENGINE 168545, Replaced By: A3661803665
999
OIL COOLER WITH COVER
999
HOSE
999
SUSPENSION EYE , Replaced By: A3522230841
999
GASKET , Replaced By: A4421870080
999
OIL LINE , Replaced By: A3441807320
999
OIL LINE OIL RETURN LINE
999
OIL COOLER , Replaced By: A3521800865
999
OIL LINE , 352.900-008-002105
999
OIL COOLER , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 730880, Replaced By: A3621800765, +001A3661880180
999
BRACKET OIL-DELIVERY/OIL-RETURN LINES
999
GASKET , Replaced By: A3521420280
999
ELBOW , Replaced By: A3520986915, +001N007603012106, +001N007604012102
999
ELBOW
999
ELBOW , Replaced By: A3520987015, +001N000961010002, +001N007603010110
999
ELBOW , Replaced By: A3520985315
999
TURBOCHARGER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3520964699
999
TURBOCHARGER
999
TURBOCHARGER
999
TURBOCHARGER , Replaced By: A3520964499
999
TURBOCHARGER , Replaced By: A3520964699
999
TURBOCHARGER , Replaced By: A3520962599
999
TURBOCHARGER , Replaced By: A3520965799
999
TURBOCHARGER
999
TURBOCHARGER , Replaced By: A3520962599
999
TURBOCHARGER , Replaced By: A3520963499, +003A0000960675, +003A0000960875
999
TURBOCHARGER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3520963399
999
TURBOCHARGER , 352.900-008-002105, Replaced By: A3520961599, +001A3521802422, +001A4421870080
999
TURBOCHARGER , 352.900-000-001758, Replaced By: A3520961599, +001A3521803020
999
SCREENING PLATE , Replaced By: A3520901434
999
SCREENING PLATE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3520901234
999
CAMSHAFT
999
CAMSHAFT , Replaced By: A3410517001
999
CAMSHAFT , Replaced By: A3520504101
999
POINTER , Replaced By: A3520321615
999
CYLINDER HEAD , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 794938YEAR OF MANUFACTURE 1984, Replaced By: A3520102021
999
GASKET , Replaced By: A3521420280
999
CLAMP FLEXIBLE SHAFT
999
SCREW PLUG , Replaced By: N000908016000
999
GASKET
999
NUT
999
LOOM TIE , Replaced By: N916017025000
999
LOOM TIE , Replaced By: N916017050000
999
LOOM TIE , Replaced By: N916017070000
999
LOOM TIE , Replaced By: N916017020000
999
LOOM TIE
999
REPAIR KIT , Replaced By: A0000900598
999
REPAIR KIT , Replaced By: A0000900080
999
REPAIR KIT MAKE AIRESEARCH,MOVING PARTS
999
REPAIR KIT , Replaced By: A0005862009
999
REPAIR KIT , Replaced By: A0005861609
999
COMPRESSOR WHEEL , Replaced By: A0000960115
999
PART NAME MISSING , Replaced By: A0010172721
999
NOZZLE , Replaced By: A0000177112
