Поз.
Артикул
Описание
3
EXHAUST PIPE FRONT,4 666521
6
PROTECTIVE PLATE FRONT EXHAUST PIPE
9
FLANGE GASKET FRONT EXHAUST PIPE TO EXHAUST MANIFOLD, UP TO CHASSIS 4 409726,FROM CHASSIS,NO LONGER REQUIRED
9
FLANGE GASKET , Replaced By: A4424920280
14
CONNECTOR FRONT,505802
14
CONNECTOR , Replaced By: A3224920207
14
CONNECTOR , Replaced By: A3224920207
17
EXHAUST MUFFLER WITH PIPE FRONT, UP TO IDENT NO. 872788 EXCEPT FOR 500033-599999
22
REAR EXHAUST PIPE REAR
22
REAR EXHAUST PIPE , Replaced By: A3604922305
22
REAR EXHAUST PIPE REAR, FROM IDENT NO. 685038 ALSO INSTALLED ON 500001-599999
28
BRACKET EXHAUST PIPE
28
SUPPORT REAR EXHAUST PIPE TO FRAME
28
SUPPORT EXHAUST PIPE,4 613839
33
SUPPORT REAR EXHAUST PIPE,5 193594
33
SUPPORT TAIL PIPE TO SIDE MEMBER
33
SUPPORT REAR EXHAUST PIPE
33
SUPPORT REAR EXHAUST PIPE
40
BRACKET , TO BE ADAPTED DURING ASSEMBLY
40
BRACKET EXHAUST MUFFLER TO CROSS MEMBER
40
BRACKET REAR EXHAUST PIPE, 872788
40
BRACKET EXHAUST PIPE SUSPENSION, 685037
45
BRACKET EXHAUST PIPE, UP TO IDENT NO. 872788 EXCEPT FOR 500033-599999
60
CLAMP REAR EXHAUST PIPE TO BRACKET
65
RUBBER BUFFER BRACKET TO SUPPORT
65
RUBBER BUFFER EXHAUST MUFFLER
67
NUT BRACKET TO SUPPORT AND TO END PIECE
999
PROTECTIVE PLATE ,FB377267
999
EXHAUST MUFFLER WITH PIPE , Replaced By: A3834900001, +001A3814920001
999
EXHAUST PIPE FRONT
999
PROTECTIVE PLATE , Replaced By: A3834900130
999
EXHAUST MUFFLER
999
PROTECTIVE PLATE INTERMEDIATE PIECE
999
CLAMP60.5 MM,4 613839
999
WASHER , Replaced By: N000125008443
999
WASHER EXHAUST MUFFLER TO STRAP
999
SCREW STRAP TO BRACKET
999
SCREW BRACKET TO FRAME SIDE MEMBER
999
SCREW CLAMP TO BRACKET AND TO PIPE
999
SCREW , Replaced By: N304017008021
999
SCREW , Replaced By: N304017008027
999
SCREW , Replaced By: N304017008034
999
SCREW , Replaced By: N304017008021
999
SCREW , Replaced By: N304017008016
999
CLAMP , Replaced By: N000000001642
999
CLAMP END PIECE TO EXHAUST PIPE 63.5 MM
999
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
SCREW PIPE CLAMP
999
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
999
SCREW BRACKET TO CROSS CONNECTION STRUT
999
NUT REINFORCEMENT TO BRACKET
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
NUT , Replaced By: N913004008001
999
NUT , Replaced By: N910113010003
