Поз.
Артикул
Описание
5
HOSE FEED & RETURN 13X1.5 MM, ORDER BY THE METER
11
BANJO UNION HOSE WIDTH, / I.D., 10/16 MM
14
CONNECTOR AT AIR COMPRESSOR, NOT USED
16
LOCK NUT FUEL FEED
18
SEAL CONE
19
NUT. UNION NUT RETURN
22
UNION NUT RETURN LINE
23
LINE FEED & RETURN
24
24
24
24
24
29
HOSE LINE CONNECTION, Replaced By: A3754760026
32
CLAMP , Replaced By: N916017011001
32
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
35
LOOM TIE LINE MOUNTING
36
CLAMP HOSE TO FLANGE AND TO VALVE
36
CLAMP DELIVERY AND SUCTION LINES TO FRAME 12/15
42
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL M8X16 MM
44
WASHER , Replaced By: A3609902340
45
WASHER BRACKET TO LEFT SIDE MEMBER
47
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
50
SCREW SHIFT LEVER TO BRACKET M8X30
53
NUT BRACKET TO FIRE WALL
53
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
62
LOOM TIE LINE MOUNTING
65
66
80
UNION NUT RETURN LINE
92
LOCK NUT FUEL FEED
104
SEAL RING FILTER INLET
170
LOOM TIE COMPRESSED AIR LINE MOUNTING 381 MM
170
CABLE TIE. LOOM TIE CABLE TO ALTERNATOR
170
LOOM TIE ELECTRIC CABLE MOUNTING
170
LOOM TIE WIRING HARNESS FOR AIR CONDITIONING SYSTEM 205 MM
185
HOSE GREEN
185
HOSE VIOLET
185
HOSE WITHE
999
FUEL COOLER
999
FITTING ON INTAKE RADIATOR-CONTROL MODULE,*0000058
999
LINE FROM CONTROL UNIT TO PUMP
999
VALVE ON INTAKE RADIATOR-CONTROL MODULE,*0000058 RECOMMENDED FOR TAKING ON STOCK TO ENGINE 559826
999
SEAL RING TO MOUNT FUEL LINES 16X22 - TO A 688 470 00 90
999
SCREW. HEXAGON HEAD BOLT BUZZER TO WINDOW LEVEL GIRDER M6X25
999
HOLLOW SCREW LINE CONNECTION TO TRANSMISSION
