Поз.
Артикул
Описание
467
SCREENING PLATE
538
HOSE PLASTIC PIPE,K 223529
594
INTERMEDIATE PIECE RETURN LINE TO INJECTION PUMP
776
BRACKET FUEL FILTER
784
SCREW STOP TO BATTERY CASE
784
HEXAGON HEAD BOLT. SCREW BRACKET TO TRANSMISSION M 10X50
784
SCREW , Replaced By: N304017010030
784
SCREW , Replaced By: N304017010053
787
WASHER , Replaced By: N000125008443
787
SPRING WASHER , Replaced By: N000137008212
787
WASHER EXHAUST MUFFLER TO STRAP
787
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
796
BRACKET OIL FILTER
798
WASHER RADIATOR TO RUBBER MOUNTING
798
WASHER BRACKET TO CONSOLE
799
SCREW BRACKET TO SIDE MEMBER M10X38
802
BRACKET
804
MOUNTING LEDGE MULTI-STAGE FUEL FILTER TO 403 092 08 40
806
SPRING WASHER CAB FLOOR
806
HEXAGON HEAD BOLT BRACKET TO SIDE MEMBER M12X1.5X35
811
SCREW , Replaced By: N308676012015
811
SCREW LEFT AND RIGHT CONSOLES TO CAB
811
HEXAGON HEAD BOLT BRACKET TO SIDE MEMBER M12X1.5X40
811
SPRING WASHER CAB FLOOR
811
SCREW CONSOLE TO CONSOLE
811
SCREW BRACKET MOUNTING
811
HEXAGON HEAD BOLT BRACKET TO BEARING BRACKET M12X35
832
FUEL FILTER FUEL FEED PUMP
834
FILTER BOWL
835
FILTER ELEMENT , Replaced By: A0000910840
837
SPRING
838
SEAL RING
840
CLAMPING BRACKET PARTS KIT
841
HOLLOW SCREW TWO-WAY VALVE,CONNECTIONS: "11,12"
843
SPACER TUBE SHOCK ABSORBER TO FRONT AXLE
844
SEAL RING INJECTION PUMP
872
BANJO UNION FUEL LINES AND BREATHING
873
SEAL RING INJECTION PUMP
874
HOLLOW SCREW FUEL LINE TO FEED PUMP
875
HOLLOW SCREW FUEL LINE TO FEED PUMP
877
INTERMEDIATE PIECE RETURN LINE TO INJECTION PUMP
891
PUMP (MANUAL AUXILIARY PUMP)
892
HOLLOW SCREW FITTING LINE CONNECTION
893
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
894
BANJO UNION FEED
894
BANJO UNION , Replaced By: N000000000363
895
FITTING RETURN
896
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
897
NUT. UNION NUT RETURN
928
BRACKET MANUAL PUMP
930
HEXAGON HEAD BOLT BRACKET TO NO.1 CROSS MEMBER M8X35
932
SCREW LICENSE PLATE TO BRACKET
932
SCREW , Replaced By: N304017006020
934
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
936
FITTING FROM FUEL FILTER TO INJECTION PUMP, RETURN
938
NUT CHECK VALVE TO AIR RESERVOIR
940
INTERMEDIATE PIECE AT INJECTION PUMP
942
INTERMEDIATE PIECE (COLLECTING HOSE CONNECTION)
944
INTERMEDIATE PIECE LINE MOUNTING
944
INTERMEDIATE PIECE , Replaced By: A3660700095, +001A0019974972, +001N915017010200
946
VALVE , Replaced By: A0000920610
946
VALVE FUEL FILTER
952
SEAL RING INJECTION PUMP
954
HOSE LEAK LINE, ORDER BY THE METER
954
HOSE PLASTIC PIPE,K 223529
956
BANJO UNION FUEL TANK-TO-FUEL-PUMP FUEL LINE
958
LOOM TIE LINE MOUNTING 280 MM
958
LOOM TIE , UP TO CHASSIS: 108.012 UNTIL PRODUCTION STOP 108.016 042417 108.018,019 043374 109.016 002452
960
CLAMP
999
SCREW , Replaced By: A4420740071
999
CLAMPING BRACKET FILTER HOUSING TO PUMP
999
PUMP , Replaced By: A0000911690, +001N915007008006
999
VALVE , Replaced By: A0000920410
999
FILTER ELEMENT , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0000922705
999
FILTER , Replaced By: A0000929301
999
FILTER , WITH METRIC THREAD 16 X 1.5, Replaced By: A0000929301
999
FILTER , WITH METRIC THREAD 16 X 1.5, Replaced By: A0000929301
999
FILTER , WITH INCH THREAD R 3/8", Replaced By: A0000900152
999
COVER , Replaced By: A4220900112
999
HOUSINGTO 001 477 14 01
999
FILTER ELEMENT , Replaced By: A3554700092
999
COVER , Replaced By: A4220900012
999
COVER , TO BE USED UP ON 001 477 71 01, Replaced By: A0000922808
999
COVER , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 401,402,403 257485 404 005659 421,422,423 051822 424 000441, Replaced By: A4220900012
999
FELT TUBE ELEMENT. FILTER ELEMENT , Replaced By: A0000922705
999
FILTER ELEMENT , Replaced By: A3554700192
999
FILTER ELEMENT , Replaced By: A0000922705
999
FILTER ELEMENT , Replaced By: A0000922705
999
FILTER ELEMENT , Replaced By: A0000922705
999
FILTER ELEMENT , Replaced By: A3554700092
999
NUT
999
STUD
999
BANJO UNION , Replaced By: N915052004007
999
CLAMP , Replaced By: N916016010201
999
CLAMP , Replaced By: N916016010203
999
FITTING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0069971672
999
INJECTION PUMP , Replaced By: A0014778601
999
FUEL FILTER , Replaced By: A0014775001
999
FUEL FILTER , Replaced By: A0014775001
999
FUEL FILTER , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS 035153, Replaced By: A0010921801
999
FUEL FILTER , EXHAUST STOCK OF OLD PARTS NUMBER FIRST 035135, Replaced By: A0010921901
999
FUEL FILTER , Replaced By: A4220900252
999
FUEL FILTER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0014774801
999
FUEL FILTER , Replaced By: A0014775701
999
FUEL FILTER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3244770001, +001A0004777215
999
FUEL FILTER , Replaced By: A0014778601
999
FUEL FILTER , Replaced By: A0014778601
999
FUEL FILTER , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 401,402,403 257485 404 005659 421,422,423 051822 424 000441, Replaced By: A4220900152
999
FUEL FILTER , Replaced By: A4220900152
999
CLAMP , Replaced By: N916016011201
999
LOOM TIE , Replaced By: A0019978490
999
PLASTIC TUBE2X4MM, ORDER BY THE METER
999
HOSE , Replaced By: A0139976782
999
HOSE , Replaced By: A0119977782
999
HOSE , Replaced By: A0119977782
999
SEAL RING
999
HOLLOW SCREW , Replaced By: N915047010100
999
HOLLOW SCREW ,4 493018, Replaced By: N915047010100
999
BRACKET AT TRANSMISSION
999
BUSHING , Replaced By: A6673210153
999
FUEL FILTER , 628057
999
SPACER TUBE SHAPED HOSE ON AIR INTAKE PIPE
999
FILTER ELEMENT , Replaced By: A4220900051
999
FILTER ELEMENT , Replaced By: A4220900051
999
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4030900140
999
SPACER TUBE , Replaced By: A3872680153
999
INTERMEDIATE PIECE , Replaced By: A4020700095
999
SCREENING , Replaced By: A4030700055
999
HOSE , Replaced By: A0119977782
999
HOSE , Replaced By: A0119977782
999
HOSE , Replaced By: A6154760326
999
BRACKET MULTI-STAGE FUEL FILTER
999
BRACKET FUEL LEAK LINE
999
BRACKET , Replaced By: A4030920540
999
BRACKET , Replaced By: A4220900041
999
BRACKET ,002101
999
BRACKET , Replaced By: A4030920840
999
BRACKET , Replaced By: A4030900741
999
BRACKET , Replaced By: A4230900341
999
ENGINE SUPPORT
999
LINE FROM PREFILTER TO FEED PUMP
999
LINE FROM INJECTION PUMP OVERFLOW LINE TO FUEL FILTER OVERFLOW VALVE
999
HOSE , Replaced By: A6154760326
999
BRACKET , NO LONGER AVAILABLE
999
BRACKET
999
HOSE , Replaced By: A0119977782
999
HOSE , Replaced By: A0119977782
999
OIL LINE
999
INTERMEDIATE PIECE , Replaced By: A4470780068
999
BRACKET , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A4070900341
999
HOSE
999
HOSE , Replaced By: A4279970982
999
BRACKET , Replaced By: A4030900741
999
HOSE , Replaced By: A4079976482
999
BRACKET
999
HOSE , Replaced By: A4079976482
999
COVER , Replaced By: A4220920108
999
BRACKET , Replaced By: A4220901241
999
FILTER , Replaced By: A4420900452
999
BRACKET , Replaced By: A4230900341
999
FILTER HEAD
999
BRACKET , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO ENGINE 421-422 105120, Replaced By: A4220900441
999
HOSE , Replaced By: A6154760326
999
HOSE , Replaced By: A6050780581
999
FITTING
999
WASHER , Replaced By: N000125008443
999
SCREW BRACKET TO SUPPORT
999
SCREW FITTING , Replaced By: A4039971172
999
HOLLOW SCREW
